3�5�2� - INSTALLATION
The correct steps to connect the devices are:
1�- Remove the protective covers of the expansion connector, which are located on the side of the de-
vices, using a flat-tip screwdriver (
2�- Insert the expansion connector and fastening clips into one of the devices (
3� Connect the two devices and fasten them by pushing the front clips down (
12
Before installing a new device, it must be disconnected the device from all power sup-
plies.
Figure 8
).
Figure 8: Installation step 1�
Figure 9: Installation step 2�
line-EDS-iMonitor
).
Figure 9
).
Figure 10
Instruction Manual
