6�1� - NETWORK SETUP
In this section, the Ethernet communications of the line-EDS-iMonitor are configured.
Host name: Identifying name within the local network.
DHCP Server: If DHCP is enabled (DHCP On), the IP address is dynamically assigned by a central
server and no further parameters need to be configured.
If this option is disabled, the IP address is fixed and the following parameters need to be configured:
 Address: IP address.
 Netmask: IP mask.
 Gateway: Gateway.
 Primary DNS server: Address of the primary DNS server.
 Secondary DNS server: Address of the secondary DNS server.
6�2� - WIFI SETUP
In this section, the Wi-Fi communications of the line-EDS-iMonitor are configured.
 Wi-Fi setup: If Wi-Fi is set to on, the following parameters need to be configured:
 Wifi SSID: Wi-Fi network identifier.
 Wifi Password: Password of the Wi-Fi network.
Clicking on
20
Figure 17: Configuration website: Network setup�
Figure 18: Configuration website: WiFi setup�
will look for available Wi-Fi networks.
