line-EDS-iMonitor
line-EDS
Note: An installation can only have one line-EDS-iMonitor device.
Note: In installations without a line-EDS-iMonitor, there can only be one line-CVM.
Note: All line-EDS-iMonitor and line-CVM devices must be connected to the auxiliary power supply.
3�5�1� - POWER ADAPTER line-M-EXT-PS
The line-M-EXT-PS is a power adapter for the line family of devices. The module connects to the left-
hand side of the devices to be fed. It can supply up to 10 VA, allowing it to power a limited number of
devices.
The maximum set it can supply is: 1 line-EDS-iMonitor + 1 line-CVM + 1 line-M (
Multiple line-M-EXT-PS can be aggregated to supply sets with power greater than 10VA. Each line-
M-EXT-PS feeds the device connected to its right (
line-M-EXT-PS
line-EDS
Note: All line-EDS-iMonitor and line-CVM devices must not be connected to the auxiliary power sup-
ply.
Instruction Manual
line-CVM
line-M line-M
Figure 5: Typical installation of a line-EDS-iMonitor with 7 devices�
line-M-EXT-PS
line-EDS
Figure 6: Maximum set a line-M-EXT-PS can supply�
line-M-EXT-PS
line-M line-M
Figure 7: Multiple line-M-EXT-PS connection�
line-M line-M line-CVM
line-CVM
line-M
).
Figure 7
line-M line-M
line-CVM
line-CVM
).
Figure 6
line-M-EXT-PS line-CVM line-CVM
11
