Other storage devices might require the installation of a
compatible controller board. See your NEC authorized
dealer for the storage devices available for your system.

Device Slots

The system has six device slots:
one 3 1/2-inch accessible device slot which contains the
standard 1.0-inch high 1.44-MB diskette drive
three 5 1/4-inch accessible device slots for 1.6-inch high
devices (one slot contains the standard CD-ROM reader
in hard disk configurations)
two internal 3 1/2-inch device slots for 1.6-inch or 1.0-
inch high devices (one slot contains the standard IDE or
SCSI-2 hard disk in hard disk configurations).
You can install accessible devices such as a diskette drive
or tape drive with a 5 1/4-inch form factor (frame) in the 5
1/4-inch slots.
You can also install a hard disk with a 5 1/4-inch form
factor in the 5 1/4-inch slots.
The following figure shows the device slot locations.
Adding Options 7-29
