EISA Configuration Utility Parameters

MENU/PARAMETER
EISA NMI Control
Software NMI
32-bit Bus Timeout NMI
Parallel Port
Parallel Port Mode
Serial Port 1
Serial Port 2
Diskette Controller
Cache Video BIOS Area
Cache Memory Region (C800)
Cache Memory Region (CC00)
Cache Memory Region (D000)
Cache Memory Region (D400)
Cache Memory Region (D800)
Cache Memory Region (DC00)
Shadow Video BIOS Area
Shadow Memory Region (C800)
Shadow Memory Region (CC00)
Shadow Memory Region (D000)
Shadow Memory Region (D400)
Shadow Memory Region (D800)
Shadow Memory Region (DC00)
Embedded — PCI SCSI Controller
Adaptec 7850 PCI SCSI Controller
Embedded — PCI IDE Controller
CMD 640B PCI IDE Controller
Standard IDE Resources
Embedded — PCI VGA Controller
Tseng ET4000 W32P (D) PCI VGA Controller
Standard VGA Resources
4-16 Using the ECU and SCSI Utilities
DEFAULT SETTING
Enabled
Enabled
Port 378 IRQ 7
Output Only
Port 3F8 IRQ 4
Port 2F8 IRQ 3
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Enabled
Disabled
Disabled
Enabled
Enabled
