Connecting EXT3-U3-T/R

PSU (Power Source Unit) at receiver side for illustration purposes only.
•
• PSU may be deployed on either the transmitter or the receiver, or both.
To connect EXT3-U3-T/R as illustrated in the example in
1. Connect the USB type B port
2. Connect the RS-232 ports:
On the EXT3-U3-T, connect the RS-232 3-pin terminal block

controller (for example, RC-208).
On the EXT3-U3-R, connect the RS-232 3-pin terminal block

controlled device ,Blu-Ray player).
Alternatively, you can connect RS-232 ports the other way around: connect a controlled
device to the EXT3-U3-T RS-232 port and a controller to the EXT3-U3-R RS-232 port.
3. Connect the USB type A ports
KAC-CAM-50M and/or a smartphone).
4. Connect the power adapter to the EXT3-U3-R and then to the mains.
EXT3-U3-T is powered via LINK RJ-45 ports
• Alternatively, you can connect the power adapter the other way around: connect
the power adapter to the EXT3-U3-T so that EXT3-U3-R is powered via the LINK
RJ-45 ports.
For best device current performance, it is recommended to connect a PSU at the
•
receiver side.
EXT3-U3-T/R – Connecting EXT3-U3-T/R
Figure 3: Connecting to the
on the EXT3-U3-T to a USB Host (for example a PC).
1
on the EXT3-U3-R to USB devices (for example,
8
EXT3-U3-T/R
Figure 3:
6
13
/ .
5 12
Kramer Electronics Ltd.
to an RS-232-
to an RS-232
7
