Kramer EXT3-U3-T User Manual page 7

20V DC Power Connector
11
Link RJ-45 Connector
12
RS-232 4-pin Terminal Block Connector
13
Service 3-pin Terminal Block Connector
14
(G, Rx, Tx)
EXT3-U3-T/R – Defining EXT3-U3-T / EXT3-U3-R USB 3.2 Gen 1 Extender−Receiver
Connect to the power adapter (when EXT3-U3-R is not powered by
PoC).
Connect to the LINK OUT port on the EXT3-U3-T.
FS: Send the FSYNC signal from the transmitter to the receiver.
Rx, Tx: RS-232 interface pass-through extension (supports any
baud rate up to 115200).
Connect for firmware upgrade.
Kramer Electronics Ltd.
5
