1-3-4.Descriptions and functions of components of product

◼
Main plate
Positioning pin hole
Connector positioning pin hole
Connector mounting hole
◼
Tool plate（Tool mounting method: Through hole）
Positioning pin hole
Connector Positioning pin hole
Connector mounting hole
For mounting bolt hole
Pilot port (For release use)
Air flow path for tool
Air port for tool
Magnet for detection of installed state of tool stand
Cam（piston）
Seal
Pilot port（For connection use）
Air port for tool
For mounting bolt hole
Manual pilot port
Slit for tool stand installation
- 10 -
Positioning pin
Steel ball
Positioning pin hole
