SMC Networks RBL Series Operation Manual

Shock absorber
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Doc. no.RB＊＊－OM0002B－B
PRODUCT NAME
Shock Absorber
MODEL / Series / Product Number
RBL(C)series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RBL Series and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks RBL Series

Summary of Contents for SMC Networks RBL Series

  • Page 1 Doc. no.RB＊＊－OM0002B－B PRODUCT NAME Shock Absorber MODEL / Series / Product Number RBL(C)series...

  • Page 2: Table Of Contents

    Table of Contents Safety Instructions P.2 to 3 1. Product Specifications 2.Construction/Parts list 3.Precations ・Selection P.5 to 6 ・Operating Environment ・Mounting P.7 to 9 ・Maintenance and Inspection ・Storage ・Life and replacement period of shock absorber P.10 －1－...

  • Page 3: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC), Japan Industrial Standards (JIS)*1) and other safety regulations*2).
  • Page 4 Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.

  • Page 5: Product Specifications

    １．Product Specifications Basic RBL1006 RBL1007 RBL1411 RBL1412 RBL2015 RBL2725 Product No. With cap RBLC1006 RBLC1007 RBLC1411 RBLC1412 RBLC2015 RBLC2725 3.92 5.88 14.7 19.6 58.8 Absorbed energy(J) Note) M10X1.0 M14X1.5 M20X1.5 M27X1.5 O.D. screw size(mm) Stroke(mm) 0.05 to 5 Impact speed (m/s) Max.

  • Page 6: Selection

    ３．Precautions Selection Danger ① Absorbed energy Select a model so that the total energy of impact objects does not exceed the maximum absorbed energy. Otherwise, it may lead to changes in the characterisitics, or damage to the product. ② Equivalent mass Select a model so that the equivalent mass does not exceed the allowable value.

  • Page 7: Operating Environment

    ④ Cutting oil, water, dust, metallic dust RBL series is a shock absorber which is used in environment where the product may be splashed by non-water soluble cutting oil. Do not use the product in conditions where a liquid such as water soluble cutting oil, water, solvent. etc. is exposed either directly or in atomized form to the piston rod, or where dust could stick to the area around the piston rod.

  • Page 8: Mounting

    Mounting Warning ① Before performing installation, removal, or stroke adjustment, be sure to cut the power supply to the equipment and verify that the equipment has stopped. ② Installation of protective cover It is recommended to install a protective cover if there is a risk of people coming close to the product while it is in use.
  • Page 9 ③ Rotating angle If the impact object rotates around a fulcrum, mount the product so that the load is applied in the direction perpendicular to the center of axis of the product. The slide load impact angle to the stroke end must be θ2<3 Allowable slide load impact angle θ...

  • Page 10: Maintenance And Inspection

    ⑥ Adjust the stopping time by using a stopper nut. Control the stopping time of an impact object by turning the stopper nut in or out (thus changing length “a”). After establishing the stopper nut position, use a hexagon nut to secure the stopper nut in place. The performance of the shock absorber is deteriorated over the time of usage.

  • Page 11: Life And Replacement Period Of Shock Absorber

    Life and replacement period of shock absorber Caution ① As a guide, the number of operating cycles (the product life) which the product can last when used according to the catalog is as follows. 1 million times RBL1006, 1007, 1411, 1412, 2015, 2725 Note) The product life (appropriate replacement period) is at an ordinary temperature (20 to 25 It depends on the operating conditions such as temperature, so in some cases the product will need to be replaced sooner than the above value.
  • Page 12 Revision history PL Law, and SI3 unit compliant Changed to be consistent with the catalog 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
