11. Then check the position of the angle display. If neces-
sary, loosen the pointer (28) with a Phillips screw-
driver, set the scale (27) to 45° position and re-tighten
the retaining screw
10.4 0°- 45° mitre cut and rotary table 0°
(Fig. 1, 3, 4, 7)
The cross-cut mitre saw can be used for mitre cuts of 0°-
45° to the left of the work surface.
ATTENTION
For mitre cuts (inclined saw head), the moveable stop
rail must be fixed in the outer position.
ATTENTION
For 0°- 45° mitre cuts, only the clamping device (work-
piece clamp) on the right must be mounted.
Tool required:
• Allen key 3 mm (D)
1. Loosen the locking screw (8b) on the moveable stop
rails (8a) and push the moveable stop rails (8a) out-
wards.
2. The moveable stop rail (8a) must be locked in a posi-
tion far enough from the inner position that the dis-
tance between the moveable stop rail (8a) and the
saw blade (6) is no more than 8 mm.
3. Before making the cut, check that no collision could
occur between the moveable stop rail (8a) and the
saw blade (6).
4. Tighten the locking screw (8b) again.
5. Move the saw head (4) to the upper position.
6. Fix the rotary table (13) in the 0° position.
7. Loosen the locking screw (23) and tilt the saw head
(4) to the left with the handle (3) until the pointer (28)
points to the desired angle on the scale (27).
8. Retighten the locking screw (23).
9. Perform the cut as described under 10.1.
10.5 0°- 45° mitre cut and rotary table
0°-45° (Fig. 1, 3, 4, 7)
The cross-cut mitre saw can be used for mitre cuts of 0°-
45° to the left of the work surface and of 0°- 45° to the
stop rail (double mitre cut).
ATTENTION
For mitre cuts (inclined saw head), the moveable stop
rail must be fixed in the outer position.
With a cross-cut saw tilted to 31.6° and a unit tilt of 33.9°,
isosceles triangular strips and profiles such as stucco
edge profiles can be mitred with the profile side down.
This is particularly advantageous for large profiles that ex-
ceed the maximum cutting height with normal insertion.
It also makes it easy to solve problems with the angle at
the corners, which is often not right-angled.
ATTENTION
For 0°- 45° mitre cuts, only the clamping device (work-
piece clamp) on the right must be mounted.
30 | GB
Tool required:
• Allen key 3 mm (D)
1. Loosen the locking screw (8b) on the moveable stop
rails (8a) and push the moveable stop rails (8a) out-
wards.
2. The moveable stop rail (8a) must be locked in a posi-
tion far enough from the inner position that the dis-
tance between the moveable stop rail (8a) and the
saw blade (6) is no more than 8 mm.
3. Before making the cut, check that no collision could
occur between the moveable stop rail (8a) and the
saw blade (6).
4. Tighten the locking screw (8b) again.
5. Move the saw head (4) to the upper position.
6. Loosen the rotary table (13) by loosening the locking
screw (7).
7. Use the handle (3) to adjust the rotary table (13) to the
desired angle
8. Retighten the locking screw (7) to lock the rotary table
in position.
9. Loosen the locking screw (23).
10. Use the handle (3) to tilt the saw head (4) to the left to
the desired angle (see also 10.2).
11. Retighten the locking screw (23).
12. Make a cut as described in 10.1.
10.6 Replacing the saw blade (6)
(Fig. 1, 4, 10, 11)
WARNING
Pull out the mains plug before carrying out
any setting, servicing or repair work!
ATTENTION
Wear protective gloves when changing the
saw blade! Danger of injury!
Tool required:
• Allen key, 6 mm (C)
1. Swivel the saw head (4) upwards and lock it with the
locking pin (25).
2. Loosen the fixing screw (5a) of the cover with a Phil-
lips screwdriver.
3. Fold the saw blade guard (5) up sufficiently that the
saw blade guard (5) is above the flange screw (29).
4. With one hand, fit the 6mm Allen key (C) to the flange
screw (29).
5. Firmly press the saw shaft lock (32), and slowly turn
the flange screw (29) clockwise. After max. one turn,
the saw shaft lock (32) engages.
6. Then undo the flange screw (29), by applying a slight-
ly greater force in a clockwise direction.
7. Fully unscrew the flange screw (29) and remove the
outer flange (30).
8. Remove the saw blade (6) from the inner flange and
pull it out downwards.
