Assembly

Always ensure that the product is stable and secured
by fastening it to a workbench, for example.
• The product must be securely installed. Secure the
product through the holes on the fixed saw table with
4 screws (not included in the scope of delivery) to a
workbench, machine stand or similar.
• Prior to commissioning, all covers and safety devices
must be mounted correctly.
• The saw blade must be able to run freely.
• In case of previously machined wood, be aware of any
foreign bodies, such as nails or screws, etc.
• Before pressing the on/off switch, make sure that the
saw blade is correctly fitted, and that moving parts run
smoothly.
• Before connecting of the product, make certain that
the data on the type plate matches with the mains
power data.
8.1 Fitting the workpiece clamp (15)
(Fig. 3)
1. Loosen the locking screw (19) and mount the left or
right workpiece clamp (15) to the fixed saw table.
2. Then retighten the locking screw (19).
8.2 Fitting the workpiece supports (18)
(Fig. 3-4)
Tool required:
• Allen key, 3 mm (D)
1. Loosen the locking screw (14) and guide the work-
piece support (18) laterally through the hole provided
on the fixed saw table.
2. Ensure that the workpiece support (18) is also guided
through the two tabs on the underside.
3. Then retighten the locking screw (14) again.
4. Repeat this process on the other side.
8.3 Fitting the stand bracket (21)
(Fig. 3-4)
Tool required:
• Allen key, 3 mm (D)
1. Loosen the locking screw (20) on the underside of the
saw and guide the stand bracket (21) through the
holes provided in the rear of the saw.
2. Then retighten the locking screw (20).
8.4 Attaching the dust bag (17) (Fig. 5)
The saw is equipped with a dust bag (17) for chips.
1. Squeeze together the metal ring on the dust bag and
attach it to the outlet opening in the motor area.
2. The dust bag (17) can be emptied via the zip on the
underside.
8.4.1 Connection to an external dust
extraction system
1. Connect the suction hose to the dust extraction.
2. The dust extraction system must be suitable for the
material to be processed.
28 | GB
3. Use a special extraction device to extract dusts that
are particularly harmful to health or carcinogenic.
9

Commissioning

9.1 Checking the safety equipment of
the saw blade guard (5) (Fig. 11)
The saw blade guard protects against accidental contact
with the saw blade and against flying chips.
Check function
To do this, fold the saw down:
• The saw blade guard must expose the saw blade
when it is swung down without touching other parts.
• When the saw is folded up to the initial position, the
saw blade guard must automatically cover the saw
blade.
9.2 Assembling the cross-cut mitre
saw (Fig. 2-4)
Note:
The cross-cut mitre saw can be pivoted left and right with
the rotary table. Exact angle adjustment is possible on the
basis of the scale.
The angle can be precisely and quickly adjusted from 0°
to 45° with locking positions at 0°, 5° 10°, 15°, 22,5°,
31,6°, 40° and 45°.
1. Loosen the rotary table (13) by loosening the locking
screw (7).
2. Use the handle (3) to adjust the rotary table (13) to the
desired angle.
3. Retighten the locking screw (7) to lock the rotary table
in position.
4. The saw is unlocked from the lower position by gently
pressing down on the saw head (4) and, at the same
time, pulling out the locking pin (25) from the engine
mount.
5. Swivel the saw head (4) upwards.
6. The clamping device (15) can be attached to both
sides of the fixed saw table (9). Insert the clamping
device (15) into the hole provided on the rear side of
the stop rail (8) and secure it with the locking screw
(19).
7. The saw head (4) can be tilted to the left to max. 45°
by loosening the locking screw (23).
8. Workpiece supports (18) must always be secured and
used during work.
9.3 Fine adjustment of the stop for 90°
chop cut (Fig. 6)
Tool required:
• 90° engineers square (A)*
* = not included in the scope of delivery!
1. Lower the saw head (4) and fix it with the locking pin
(25).
2. Loosen the locking screw (23).
3. Place 90° engineers square (A) between saw blade
(6) and rotary table (13).
4. Loosen the locknut (26a).
