5. Adjust the adjustment screw (26) until the angle be-
tween the saw blade (6) and the rotary table (13) is
90°.
6. Re-tighten the locknut (26a).
10 Operation
10.1 90° chop cut and rotary table 0°
(Fig. 1, 3, 4, 7)
ATTENTION
For 90° chop cuts, the moveable stop rail must be fixed
in the inner position.
Hints for clamping:
• Do not work with workpieces that are to small to be
clamped in place.
• Reinforce very thin workpieces by sawing through
them together with an additional bar. Very thin work-
pieces may "flutter" or break when sawing
Tool required:
• Allen key 3 mm (D)
1. Loosen the locking screw (8b) on the moveable stop
rail (8a) and push the moveable stop rail (8a) inwards.
2. The moveable stop rail (8a) must be locked in a posi-
tion far enough from the inner position that the dis-
tance between the moveable stop rail (8a) and the
saw blade (6) is no more than 8 mm.
3. Before making the cut, check that no collision could
occur between the moveable stop rail (8a) and the
saw blade (6).
4. Tighten the locking screw (8b) again.
5. Move the saw head (4) to the upper position.
6. Place the wood to be cut against the stop rail (8) and
on the rotary table (13).
7. Secure the material with the clamping device (15) on
the fixed saw table (9) to prevent it from shifting during
the cutting process. See point 10.9
8. Unlock the locking switch (2) and press the on/off
switch (1) to switch the motor on.
9. Move the saw head (4) with the handle (3) evenly and
with light pressure downwards until the saw blade (6)
has cut through the workpiece.
10. When the sawing process is finished, return the saw
head to the upper resting position and release the ON/
OFF switch (1).
ATTENTION
The return spring automatically raises the product. Do
not release the handle after finishing cutting but allow
the saw head to move upwards slowly and with a little
counterpressure.
10.2 90° chop cut and rotary table 0°-45°
(Fig. 1, 3, 4, 7)
The cross-cut mitre saw can be used for angled cuts of
0°-45° to the left and right.
ATTENTION
For 90° chop cuts, the moveable stop rail must be fixed
in the inner position.
Tool required:
• Allen key 3 mm (D)
1. Loosen the locking screw (8b) on the moveable stop
rail (8a) and push the moveable stop rail (8a) inwards.
2. The moveable stop rail (8a) must be locked in a posi-
tion far enough from the inner position that the dis-
tance between the moveable stop rail (8a) and the
saw blade (6) is no more than 8 mm.
3. Before making the cut, check that no collision could
occur between the moveable stop rail (8a) and the
saw blade (6).
4. Tighten the locking screw (8b) again.
5. Loosen the rotary table (13) by loosening the locking
screw (7).
6. Use the handle (3) to adjust the rotary table (13) to the
desired angle.
7. Retighten the locking screw (7) to lock the rotary table
(13) in position.
8. Make a cut as described in 10.1.
10.3 Fine adjustment of the stop for 45°
mitre cut (Fig. 1, 3, 4, 7, 8, 9)
Tool required:
• Allen key 3 mm (D)
• 45° engineers square (B)*
* = not included in the scope of delivery!
1. Lower the saw head (4) and fix it with the locking pin
(25).
2. Fix the rotary table (13) in the 0° position.
ATTENTION
For mitre cuts (inclined saw head), the moveable stop
rail must be fixed in the outer position.
3. Loosen the locking screw (8b) on the moveable stop
rails (8a) and push the moveable stop rails (8a) out-
wards.
4. The moveable stop rail (8a) must be locked in a posi-
tion far enough from the inner position that the dis-
tance between the moveable stop rail (8a) and the
saw blade (6) is no more than 8 mm.
5. Before making the cut, check that no collision could
occur between the moveable stop rail (8a) and the
saw blade (6).
6. Tighten the locking screw (8b) again.
7. Loosen the locking screw (23) and tilt the saw head
(4) to the left, to 45°, using the handle (3).
8. Place 45° engineers square (B) between saw blade
(6) and rotary table (13).
9. Loosen the locknut (22a) and the adjustment screw
(22) until the angle between the saw blade (6) and the
rotary table (13) is exactly 45°.
10. Re-tighten the locknut (22a).
