LUNA OPTICS QUANTUM DIGITAL 2K Instruction Manual page 7

Press button (7) momentarily again. The icon
level 2.
Press button (7) once again, the icon
Press button (7) once again and the infrared light will be turned off. You can circularly adjust the
infrared light brightness among these 3 levels.
When the infrared light (1) is turned on, you can rotate the IR lens (1) to adjust the width of the IR
beam. When the IR beam is focused/narrowed, you will see smaller illuminated area, but further in
the dark, when the beam is widened, you will see wider illumination, but over a shorter distance.
WARNING: Class-3R laser product
When infrared light is turned on, do not look directly into the infrared
light beam lens (1).
Staring into the infrared beam for a long time may damage your eyes.
Still Image (Photo) Capture
Press Photo/Video button (6) momentarily to take photo. The countdown timer has 4 options: Instant
/ Delay 3 seconds / Delay 5 seconds / Delay 10 seconds. You can select the option in the main
menu: press Controller (M) for 2 seconds to enter main menu, scroll down to Settings, then select
Photo Timer function and select desired countdown time option.
Video Recording / Video Resolution
Press and hold Photo/Video button (6) for 2 seconds to activate video recording. Press and hold the
same button for 2 seconds again to stop recording video. There are three different resolution options
for video recording: 2K / 1080P / 720P, which can be selected from the main menu. Press controller
(M) for 2 seconds to enter the main menu, scroll down to Settings, then select Resolution option.
Video recording tips:
1. Pay attention to the distance focusing while video recording. Keep one hand near the distance
focusing wheel (2) and you will be able to quickly adjust focus when necessary.
2. If you are recording moving objects, we strongly recommend using a quality tripod to minimize
handshakes during recording.
During video recording you can take still image (photo) by pressing button (6) momentarily. A green
camera icon will display on the top left corner, indicating the still image has been captured.
will be shown. It means the IR brightness is on
will be shown. It means the IR brightness is on level 3.
