- Page 1 LN-DB60-HD HIGH DEFINITION DIGITAL DAY & NIGHT BINOCULAR / RECORDER INSTRUCTION MANUAL IMPORTANT: Please read this manual in its entirety prior to using this device!
- Page 2 DIGITAL DAY/NIGHT VISION: 1. Your new binocular operates with batteries. Unlike a daylight binocular, where you see the image due to light traveling through the glass and the prisms, the digital night vision device works by processing the image with the internal CCD or CMOS sensor and projecting the image onto an LCD screen.
-
Page 3: Operation
YOUR SYSTEM INCLUDES THE FOLLOWING: 1. LN-DB60-HD Digital Night Vision Viewer/recorder 2. 8GB Micro SD-card (installed into the SD-card slot) 3. Color Enhancing Filter (Daylight use only for vivid colors) 4. Carry case with shoulder strap 5. Padded neck strap 6. - Page 4 LN-DB60-HD DIGITAL BINOCULAR / RECORDER Glossary: 1 – Objective Lens Focusing Wheel 9 – IR Beam Brightness Wheel 2 – Video Record Button 10 – Accessory Mount 3 – Still Image Button 11 – USB / Micro-SD Card Ports 4 – Image / Zoom Button 12 –...
-
Page 5: Installing The Batteries
INSTALLING THE BATTERIES: Your digital day/night vision unit operates on a single 3.7V rechargeable battery type 18650 available at Amazon and other online retailers. NOTE: it is possible to use either regular or rechargeable CR123 batteries, but working time may be reduced and batteries connection may not be 100% reliable WARNING: if 2xCR123 batteries are supplied with the unit –... -
Page 6: Setting Up Date And Time
10seconds, please try to decrease the brightness of the image by gently toggling the Brightness Wheel (8) either left or right. CONNECTING THE DC ADAPTER: Your digital binocular can also operate from a common wall outlet with the use of the plug adapter (included). Insert the adapter cord into the IMPORTANT: DC Output (12) and connect adapter to the wall outlet. - Page 7 FOCUSING THE UNIT: To obtain the sharp image, you must first rotate the objective lens (1) in either direction, until you notice in which position the image is at its best. After that, rotate the oculars (7) also until the image is at its best. You may have to repeat the process again, until the image is sharp and clear.
- Page 8 Since the image sensor does not actively amplify the available light, you will need to utilize the IR illuminator often in the nighttime conditions. To turn the Infrared illuminator ON, press the IR illuminator button (6) momentarily – image will remain full color. To switch image to night vision green (Sephia option) –...
- Page 9 pressing onto its end. It will pop out of its slot. Gently remove the card and replace it with the new one by pressing it straight forward until it is securely locked in the slot. Close tightly the rubber compartment cover to protect the card from water and/or dust.
- Page 10 momentarily just once. You will be able to switch between images and videos by pressing IMAGE button (4) in either + or – direction. To play the recorded video, press PIC button (3) once. To stop playing video press PIC button again. To exit picture/video viewing mode and to come back to the active image mode, press Power button (5) briefly just once.
-
Page 11: Troubleshooting
8. Close the app and open the App again and click on “Connect Camera” 9. Green check (√) sign means camera is now connected 10. Follow on screen menu on your mobile phone to utilize the available features of the app. TROUBLESHOOTING: 1. -
Page 12: Technical Specifications
Power________________2 x 3V Lithium (CR123) or 1 x 3.7V type 18650 Operating Time _________________2.5-3hrs (2xCR123) __4hrs (18650) Dimensions______________180mm x 120mm x 60mm (7.2”x4.7”x2.3”) Weight__________________________________________ 725g (1.6lbs) Warranty_______________________________________________1yr --------------------------------------------------------------------------------------------------------- LUNA OPTICS, INC. 300 Hawthorn Dr., Fate, TX 75087 (USA) E-mail: info@lunaoptics.com Web: www.lunaoptics.com © 2018...
