LUNA OPTICS QUANTUM DIGITAL 2K Instruction Manual page 9

Wi-Fi function
1) On mobile phone, download and install the APP. NOTE: APP information will be provided on a
separate paper. Then turn off the Wi-Fi on your mobile phone.
2) On the binoculars, press and hold the controller (M) for 2 seconds to enter the main menu, select
Wi-Fi function and activate it. You will be able to see the following:
Wi-Fi Name: M9-9803cf2185ac (M9 is the Wi-Fi name, 9803cf2185ac is the serial number of Wi-Fi
(every device has a unique serial number.)
Wi-Fi Password: 12345678 (12345678 is the factory default password. Once the device and mobile
phone are connected, users can change the password on mobile phone via the APP.)
3) Now turn the Wi-Fi back on your mobile phone. On the WLAN menu of mobile phone, search for
the device Wi-Fi name (in this example it is M9-9803cf2185ac) (reminder: every product has a
unique serial number, so please check the binoculars screen for exact Wi-Fi name), and then click
Connect, and type in the corresponding device Wi-Fi password 12345678 to connect. At this time,
the mobile phone will display: Connected (no Internet access). If a mobile phone pops up a dialog
box: The current WLAN is not available, do you want to continue using this WLAN? Or anything
similar to that, you should select to use this WLAN at this time. Then exit the WLAN connection
interface on the mobile phone.
4) On the mobile phone, click to open the installed APP. On the APP interface, click the icon in the
middle of the screen. Now the mobile phone and device should connect successfully. After
connection, the APP displays the real-time image of the device and enters the recording mode. To
exit the APP connection, press and hold the controller "M" for 2 seconds on your device.
Wi-Fi Tips:
1. If the connection between the APP and the device is unsuccessful, please turn it off and restart the device
to connect again.
2. Device should be kept within 10m / 11yds within the mobile phone, in the open space for good connection,
otherwise the signal may weaken, and the connection may not be reliable.
Electronic compass function
Press and hold the controller (M) for 2 seconds to enter the main menu. Scroll down to and select
Electronic Compass function, then select On, short press controller (M) to activate the electronic
compass function. Press and hold the controller (M) for 2 seconds to exit the main menu and the
