Using Ir Illuminator - LUNA OPTICS QUANTUM DIGITAL 2K Instruction Manual

Once Main Menu is activated, all Menu navigation is done the following way:
Scrolling through the menu contents: rotate the multi-controller (M) in either
-
direction (each click scrolls the menu by one step)
Selecting and confirming function: short press onto the multi-controller (M)
-
Return from selected function to Main Menu: Press and Hold onto multi-
-
controller (M) for 2 seconds.
Return from subchapter or from 2
-
press multi-controller (M).
Exiting the Main Menu: Press and Hold onto the multi-controller (M) for 2
-
seconds.
QUICK SUB-MENU: Ultra Night Vision Mode / display brightness / image color
If you wish to keep the IR light off in dark conditions, you may utilize Ultra Night Vision Mode. Press
controller (M) once momentarily to enter the quick sub-menu
controller (M) to select ultra night vision level 1/2/3. The ultra night vision function will be turned on
automatically. The night vision image will be brighter at short distances (approx. 25yds and closer)
when ultra night vision is activated.
Press controller (M) twice momentarily to enter display brightness menu
(M) selects displays brightness between levels 1 ~ 6, and the display brightness adjustment function
is activated automatically once the level is selected. The higher brightness level means brighter
display image.
Press controller (M) momentarily 3 times to enter color menu
between the 6 color options: Daytime Color / Low-Light Full Color / Black & White / Green / White
Phosphor / Amber, and the display color adjustment function will be changed.
Ultra Night Vision Mode tips:
1. In dark conditions where the infrared light needs to be turned off, turn on ultra night vision to the highest
level 3 and display brightness to level 5 or 6, in order to get the best effect of ultra night vision mode. The
ultra night vision is designed for dark conditions only and should not be activated in daylight. If you turn on
the IR illuminator, the device will switch to ordinary night vision mode automatically and ultra night vision
mode will be disengaged.
2. Ultra night vision function must be activated manually each time you power the binocular, and it will not
stay on after the binocular is turned off and then turned on again later.

Using IR Illuminator:

In dark conditions (generally ½ Moon and darker) you might need to activate built-in 850nm infrared
light. Press Power/IR Illuminator button (7) momentarily. The icon
right of the screen. It means the 850nm infrared light is turned on and the IR brightness is on level
1.
nd page: highlight "Back" circle and short
, then immediately rotate
. Rotating controller
. Rotate controller (M) to select
will be shown on bottom
