Technical Specifications - LUNA OPTICS QUANTUM DIGITAL 2K Instruction Manual

and is also considered the most reliable format.
In order to re-format the card you must run it through a 3
Partition. While nearly all of the providers would want you to buy their upgraded versions, you can
just download their basic freeware version, and it would be sufficient to re-format the card. Disk
Partition seems to be the most simple and hassle-free provider we could find:
https://www.disk-partition.com/download.html
• Download the "Standard Free" version and follow all the download instructions.
• Once downloaded, open the program, and insert the micro-SD card into the computer.
• Highlight the correct disc by single-click and then choose on the bottom left side of the
menu to "Format Partition" (alternatively right-click on the highlighted disc and choose the
same function). A pop-up window will appear. You can label your partition (such as
"Luna Optics Binocular" or any other name you desire (it's optional) and then make sure to
select "FAT32" as the File System. Then click "OK".
• Once the format is finished, click on "Apply" located in the upper left corner. You must
select "Apply" otherwise the formatting is not finished.
• Your card is now formatted, but before you can use your 64-512GB card in our digital night
vision product you must also format the card inside the product. To do so, insert the card
into its slot (14), turn your binoculars on and through the menu find and select "Format",
then select "OK". Once the card is formatted inside the night vision device it is now ready
to use.

Technical Specifications:

Image Sensor:------------------------------------------------------------------------Large Format, Quantum Digital, 120fps
Nighttime Sensitivity:----------------------------------------------------------------0.0015lux
Image Displays:----------------------------------------------------------------------AMOLED 0.39" HD
Maximum Video Resolution:------------------------------------------------------2880 x 2160 (4K)
Still Camera Resolution:-----------------------------------------------------------5360 x 3008 (16.12MP)
Image Magnification:----------------------------------------------------------------6x (optical) - up to 36x (digital)
Objective Lens Specifications: ---------------------------------------------------50mm (F1.0) Fast Light Transmitting
Field Of View:------------------------------------------------------------------------10°
Interpupillary Distance:-------------------------------------------------------------60 – 71mm (adjustable)
Diopter Adjustment:-----------------------------------------------------------------+/-5
Visual range (1/4 moon, IR on):--------------------------------------------------0.8m to 400m (building)
Visual range (Full Moon):----------------------------------------------------------0.8m to 1200m (building)
Visual Range (Daytime):-----------------------------------------------------------0.8m to infinity
IR Illuminator:-------------------------------------------------------------------------850nm
Video Output:-------------------------------------------------------------------------1x HDMI (1080p)
rd party provider. We suggest using Disk
