Notes:
If there is no video format YUY2 after setting above, check the USB 3.0 port connection. Make
sure it is linked to USB 3.0 port on PC by a USB 3.0 cable. (USB 3.0 cable or port is standard in blue while USB
2.0 is in black). If the captured picture flashes, change the video format to YUY2.
Audio Setting
When there is no audio playing, check the video source to see if it is set as default value, and then check the
audio setting on OBS.
1. Set default for the audio source.
2. Audio setting on OBS.
Choose "Audio", click "Setting" and choose audio device (MIC/Auxiliary Audio Device).
Synchronize Video with External Audio
When the video itself doesn't have embedded audio and needs insert external audio, here are the steps:
