Key Features - RGBlink mini-ISO User Manual

1.2.1 Key Features

• Mini and convenient to carry
• 3.5-inch TFT touch screen for menu operation, signal preview, and working
status display
• 4-CH HDMI 2.0 inputs (HDCP 1.4 compliance), resolution up to 4K@60
• 4-CH SDI inputs support signal from camera, recorder, etc
• 2-CH HDMI 1.3 outputs for monitoring of multiviewer, Program, or Test Pattern
• Seamless video switching between 5 channels (4 x HDMl / SDl and 1 x NDl/UVC) with
transition effects
• 4-CH HDMI/SDI for mixed signals and 2-channel external audio mixing support
• UVC input supports signal from webcam, UVC Camera, USB capture, etc
• NDI encoder output as an NDI source in the ethernet range
• T-bar switch and 15 transition effects support
• Fast mode and preview switch mode support
• USB 2.0 for recording in exFAT or FAT32 format with bitrate up to 16Mbps
• USB 3.0 output supports YUY2 or MJPEG format, which can be recognized as webcam for
streaming or capture
• RTMP(s) network streaming up to 4 platforms
• One NDI output support
• Independent control of PTZ, zoom, and focus of up to 5 PTZ cameras; fast view saving
and view recall.
• 5-direction joystick and toggle for controlling PTZ camera (IP VISCA Protocol supported)
• Specify either "green" or "blue" as the key color for Chroma Key
• TAO Cloud control support, compatible with mobile devices and desktop
9
mini-ISO User Manual
