Danfoss iC7 Series Operating Manual page 29

Functional Extensions
Operating Guide
230 V AC
L1
L2
L3
PE
Illustration 19: Operation above 2000 m (6560 ft) Altitude with Voltage above 50 V AC
24 V DC
230 V AC
L1
L2
L3
PE
Illustration 20: Operation above 2000 m (6560 ft) Altitude with Mixed Voltages
6.7 Parameter Descriptions for Relay Option OC7R0
To set Relay output, see parameter group 5.26.1 General Digital Outputs.
Table 18: Digital Output Mapping for Relay Option OC7R0
Bit number
15
14
13
12
11
10
Danfoss A/S © 2022.12
Terminal X101
COM NO
1 2
3
NC
Terminal X102
COM NO
4 5
6
NC
Terminal X103
COM NO
7 8
Terminal X101
COM NO
1 2
3
NC
Terminal X102
COM NO
4 5
6
NC
Terminal X103
COM NO
7 8
Relay Option Installation and
Value
–
Relay 8
Relay 5
Relay 2
–
–
AQ390830267692en-000501 / 136R0273 | 29
Configuration
