Danfoss iC7 Series Operating Manual page 18

Functional Extensions
Operating Guide
Resolver excitation + 2
Resolver excitation –
1
Track A +
18
Track A – 16
Track B + 14
Track B – 12
Plug detect + 13
Plug detect – 11
Illustration 8: Wiring Configuration for Resolver
5.6.4 Resolver with Mirror Out
When using a resolver, a TTL encoder signal can be generated to mirror the resolver signal. The mirroring enables transferring the
shaft position to other devices for monitoring, or further control. The encoder output signal can be scaled by defining the number
of pulses representing 1 rotation of the resolver.
Table 10: Parameters for Resolver with Mirror Out
Parameter
9.4.1 Interface Configuration
9.5.2 Resolution Channel 2
9.7.1 Excitation Voltage
9.7.2 Excitation Frequency
9.7.3 Number of Poles
Resolver excitation +
Resolver excitation –
Channel A +
Channel A –
Channel B +
Channel B –
Channel Z +
Channel Z –
Channel D +
Channel D –
Plug detect +
Plug detect –
Illustration 9: Wiring Configuration for Resolver with Mirror Out
1 Resolver
2 Controller, or other device
18 | Danfoss A/S © 2022.12
Ref +
Ref –
Sin +
Sin –
Cos
Cos –
Setting
Set to [8] Resolver A,B + Mirror out Z,D.
Set the required number of pulses for the encoder output representing 1 rotation of the resolver.
Set the excitation voltage according to the specification of the connected resolver.
Set the excitation frequency according to the specification of the connected resolver.
Set the number of poles of the connected resolver.
2 Ref
1 Ref –
Sin +
18
16
Sin –
Cos
14
12
Cos –
10
8
6
4
13
11
Encoder/Resolver Installation and
1
2
A
A –
B +
B –
AQ390830267692en-000501 / 136R0273
Configuration
