Functional Extensions
Operating Guide
If the Plug detect connection is missing while the interface is activated (parameter 9.4.1 Interface configuration ≠ "Disabled"), the
drive generates a fault.
-
The fault is generated only when switching to closed-loop operation, not when selecting an encoder.
-
The plug connector is delivered without a connection between pin 11 and 13.
Table 3: Pin Assignment and Function for Encoder/Resolver Option OC7M0
Numbering Functions
1 Resolver Excitation -
3 GND
5 GND
7 Encoder Supply Sensor -
9 Encoder Supply Sensor +
11 Plug Detect - (GND)
13 Plug Detect +
15 Encoder Supply - (GND)
17 Encoder Supply +
5.5 Encoder/Resolver Option OC7M0 Specifications
Voltage can be up to 24 V. Setting the voltage too high can damage the connected encoder.
The voltage is configured in parameter 9.4.4 Encoder Supply Voltage. For details, refer to
Table 4: Electrical Specifications for Encoder/Resolver Option OC7M0
Encoder supply voltage [V DC]
24
15
12
8
5
If the available power is insufficient, it is possible to use an external power supply for the encoder.
Table 5: Device Type Specifications
Device type Specifications
Data
TTL (A, B, Z) Signal level
Maximum resolution
12 | Danfoss A/S © 2022.12
N O T I C E
Numbering Functions
2 Resolver Excitation +
4 Ch. D- (TTL, RS-485, HIPERFACE DSL®)
6 Ch. D+ (TTL, RS-485, HIPERFACE DSL®)
8 Ch. Z- (TTL, HTL, RS-485, R-)
10 Ch. Z+ (TTL, HTL, RS-485, R+)
12 Ch. B- (TTL, HTL, RS-485, Analog B-)
14 Ch. B+ (TTL, HTL, RS-485, Analog B+)
16 Ch. A- (TTL, HTL, RS-485, Analog A-)
18 Ch. A+ (TTL, HTL, RS-485, Analog A+)
N O T I C E
Maximum current [mA]
125
150
150
225
300
Additional information
Value
0–5 V Differential signals are preferred, but single signals are
also supported. The trigger threshold is 0.33–0.4 times
65535
the encoder supply voltage.
Encoder/Resolver Installation and
5.7.1 Configuration (Menu Index
(1)
AQ390830267692en-000501 / 136R0273
Configuration
9.4).
