Functional Extensions
Operating Guide
Device type Specifications
Data
Maximum frequency
Maximum cable length
HTL (A, B, Z) Signal level
Maximum resolution
Maximum frequency
SinCos Signal level
Maximum resolution
Maximum frequency
SSI Maximum resolution
Maximum data length
Maximum clock frequency
EnDat Maximum resolution
Maximum data length
Maximum clock frequency
HIPERFACE DSL® Maximum resolution
Maximum data length
Baud rate
BiSS Maximum resolution
Maximum data length
Maximum clock frequency
Resolver Excitation voltage
Excitation frequency
Maximum number of poles
Maximum input voltage
Maximum load
Encoder simula- Voltage level
tion (TTL Output)
Danfoss A/S © 2022.12
Additional information
Value
750 kHz
Depends on sig-
nal frequency
0–24 V
65535
500 kHz
1 V peak-peak –
65535
750 kHz
31 bit –
63 bit
2 MHz
31 bit Both EnDat 2.1 and EnDat 2.2 are supported, but only
with pure absolute channel, not with incremental chan-
63 bit
nel.
8.33 MHz
31 bit Baud rate is fixed.
63 bit
10 Mbps
31 bit –
63 bit
8.33 MHz
2–8 V –
rms
2–20 kHz
254
8 V
rms
100 mA
rms
Minimum: 1.5 V –
Typical: 2 V differ-
ential
