Intergraph StudioZ System Manual page 34

System Guide
Installing the Audio
Driver
26
5. When the test is complete, click Yes. If you did not see the test bitmap
properly, verify the settings and repeat the test. If the problem persists,
contact your system reseller.
6. Click OK to close the Display Settings dialog box.
The display is configured.
Before installing the Antex driver, you must remove any previous versions.
Once the driver is installed, you must set the Windows NT multimedia
properties, and set the Antex mixer. It is very important that you set the
sample clock in the Antex mixer.
!
Do not stop the Antex driver before removing it. If you do, you will
have to log off and then log on and restart the Antex driver.
To remove the Antex driver
1. In the Windows NT Control Panel, double-click the Multimedia icon.
2. In the Multimedia property editor, select the Devices tab.
3. Click the plus (+) sign next to Audio Devices to expand the folder.
4. Select Audio for Antex Digital Audio Driver and click Remove.
5. In the Windows Explorer, open the C:\Winnt\system32\Drivers folder and
delete the AntexWAV.sys file.
6. Delete the C:\Antex folder.
System Guide
