Additional Peripherals
and Cables
Download from Www.Somanuals.com. All Manuals Search And Download.
Reference Documentation
In addition to the software documentation previously listed, the package
contains hardware manuals and other reference material:
• Running Microsoft Windows NT Workstation Version 4.0 by Craig Stinson
and Carl Siechert (Microsoft Press, Redmond, WA).
• Digital Multi-Scan Color Display Operating Instructions.
• WACOM artZII User's Manual.
• Intergraph StudioZ System Setup.
• StudioZ Late-Breaking News.
A typical workstation requires that you provide the following additional
peripherals:
Device Description
House Sync The house sync must have the same video format (NTSC or PAL) as
your video equipment and as the project that you create in
SOFTIMAGE|DS.
Video Monitor NTSC or PAL
Digital or Analog.
Video Cassette Analog or digital VCRs connect to the base unit through a RS-422
Recorder (VCR) cable.
Analog devices require A/D converters which are available from your
system reseller.
A/D Converter An A/D converter is required when using an analog VCR.
Waveform Monitor This device is used for luminance video signal control.
Vector Scope This device is used for chrominance video signal control.
Speakers and Amplifier Analog and/or digital audio equipment connects to XLR connectors.
Cables Video: Use high quality 75-ohm coaxial cables with 75-ohm BNC
coaxial connectors.
Audio: Use analog XLR connectors and digital XLR connectors.
Intergraph Cable This kit contains keyboard, mouse and monitor extension cables with
Extension Kit an amplifier. It is required if you place the base unit more than 6 feet
from the monitor, keyboard, mouse, and WACOM tablet.
The use of any other extension cables may cause signal
degradation.
For more information on optional equipment, contact your system reseller.
