InterPuls milkrite Cluster Flush User Instruction Manual page 21

Original instructions
Installation diagram of the accessories
Compressor
A compressor needs to be installed to allow the dispensing of air in the system.
This device is not supplied by Interpuls.
It is recommended to use a compressor that does not run an oil and to install the special filter and pressure
regulator at the outlet.
WARNING
Do not set a pressure higher than 2.5 bar (73.8 "Hg). Failure to comply with the above may
cause damage to the milking components concerned by the cleaning action.
This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
Part Description
1 Water filter
2 Dispenser
3 Water pump + tank
21
5730018_06.22_EN
