InterPuls milkrite Cluster Flush User Instruction Manual page 12

5730018_06.22_EN
Terminal
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
The components inside the unit are already wired. You need to connect only the external parts,
such as CV and milking panel.
This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
Cable colour Utility
/ Not used
/ Not used
/ Not used
/ Washing bypass
/ Washing bypass
/ Not used
/ Not used
Water solenoid valve
Not included
Common General
Not included
Compressed air Solenoid Valve
Not included
Output solenoid valve
Not included
CV (COM contact)
Not included
CV (cylinder contact)
Not included
/ Not used
/ Not used
White
Cylinder activation panel terminal (neutral)
Brown
Cylinder activation panel terminal (phase)
12
