Connection to the milking panels.
The Cluster Flush panel can be used with all InterPuls panels. The start contacts of the cluster washing
phase must be connected to the terminals indicated in the table below.
Please refer to the manuals of the panels for additional details about their connections.
In case of need, contact the Helpdesk InterPuls service
This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
Panel
iMilk600
ACR Smart
iMilk401
16
Panel Contact
CYL- J6
GND- J6
13
14
E5-SO
CE5-SO
