Installing the components
In order to install the piping of the system, follow the indications provided in the diagram below.
Ø 14 mm (0.55 in)
Max 2.5 Bar
73 8 "Hg
This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
Ø 14 mm (0.55 in)
Number Description
1 Water line
2 Air line
17
5730018_06.22_EN
Min 35 cm
(13.78 in)
