- Page 1 LE30 Technician and User Instruction Manual...
- Page 3 Periodical maintenance ....................... 14 SPARE PARTS DIAGRAM ........................15 LE30 with 3-pin cable ........................15 LE30 with 4-pin cable ........................16 TROUBLESHOOTING .......................... 17 This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 4 Certain company and product names used throughout the document are trademarks of their respective owners. This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 5 2.1.4 Limitation of liability InterPuls S.p.A. declines all liability for damage to persons, animals and/or things caused by incorrect use of the equipment. This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 6 Use powder, foam or halogen extinguishers which must be positioned next to the device. Operating personnel must receive adequate instruction on how to use the extinguishers. This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 7 Directive WEEE Waste Electrical & Electronic Equipment • Regulation (CE) No 1907/2006– concerning the Registration, Evaluation, Authorisation and • Restriction of Chemicals (REACH) UKCA (UK Conformity Assessed) • This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 8 4 pins allow separate management of the common cable. LE30 pulsators can have filter cartridges or can be connected directly to the filtered air line. This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 9 A kit is available for the quick mounting and dismounting of the pulsator from the vacuum line, which is highly recommended as it allows maximum evacuation capacity of the pulsator (see chap. 6.1 Quick Mounting 6.2 Adaptable Quick Mounting) This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 10 Unforeseen use All those not specified within Chapters 3. 6 ASSEMBLY Quick Mounting Installation on vacuum line with Quick Mounting and filtered air connection This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 11 Installation on vacuum line with Quick Mounting adaptable to DL rooms with bayonet coupling OUTER O-RING INNER O-RING WARNING Mount the bayonet on the main line without vacuum Filtered air connection This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 12 LE30 with 3-pin cable: Brown: Front Black: Common Blue: Rear to pulsators LE30 with 4-pin cable: Black – Blue + Black – Blue + This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 13 If the milking parlour is very damp and dusty, cleaning should be carried out once every 3 months. WARNING Do not lubricate the filter with oil This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 14 The user retains responsibility for correct installation and maintenance. Please contact your local milkrite | InterPuls dealer or sales representative for assistance if required. This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 15 LE30 with 3-pin cable 1.5m Brown Black Blue Gray ID=3mm 1.5m Brow n + Black - Blue + Ref. 1060281 - 08/22 Gray - ID=4mm This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 16 Gray Blue Brown Black Brown Black Blue Gray 1.5m Brow n + ID=3mm Black - Blue + Gray - Ref. 1060048 - 06/22 ID=4mm This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
- Page 17 Ensure that the pistons and the body on which they grip are free of dirt. If necessary, perform maintenance with Service Kit S002 or S003 This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
