Use and Maintenance Instruction Manual
TOP WASH
(Software Version 2.0)
InterPuls S.p.A.
Via F. Maritano, 11 - 42020 - Albinea (RE) – ITALY
Tel. +39 0522 347511
Fax +39 0522 348516
sales@interpuls.com
InterPuls S.p.A.
-
IL PRESENTE MANUALE È PROPRIETÀ DELLA -
OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA
