4 TECHNICAL FEATURES
Technical Specifications
Model
Maximum inlet water pressure
Power supply
Fuses
Maximum absorption
Dimensions (LxLxA)
Wiring diagram
WARNING
Check the board type before proceeding with wiring
This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
Cluster Flush
10 bar
24 ± 10% VDC
Self-regenerating fuses
600 mA
120 x 200 x 90 mm (4.72 x 7.87 x 3.54 in)
