5 PROGRAMMING THE DEVICE
In order to program the device, you need to use the dip switches located on the board
1
2
Water
Air
Pause
3
4
Waiting
Cycles
5
6
Cylinder
This makes it possible to define the system operating times.
In particular, the following parameters can be set:
- Water dispensing time
- Air dispensing time
- Pause between water and air dispensing
- Waiting time after removal of the cluster
- Number of cycles (1 or 2)
- Position of the cylinder while the cluster is being washed (low or high)
This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
OFF ON OFF ON
5 sec 6 sec
3 sec 4 sec
2 sec 2 sec
OFF ON OFF ON
7 sec 10 sec
Default
OFF ON OFF ON
1 Cycle 2 Cycles
Low High
18
Original instructions
Default
OFF ON OFF ON
8 sec 7 sec
5 sec 5 sec
2 sec 2 sec
OFF ON OFF ON
25 sec 35 sec
