5730018_06.22_EN
Original instructions
4.1.2 Wiring diagram with type 2 board
Washing bypass
(not supplied)
Panel
CV
Compressed air
Water solenoid valve
Solenoid Valve
Output solenoid valve
This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
13
