Intellitronix DP/BG10003 Installation Manual page 8

To calibrate:
1. Locate a measured mile or KPM where you can safely start and stop your
vehicle. By running the vehicle over this measured distance, the speedometer will
learn the number of pulses outputted by the speedometer sensor during a specific
measured distance. It will then use this acquired data to calibrate itself for accurate
reading. There is a small recall pushbutton in the center of the panel used to calibrate
and read all the data stored in the speedometer. After installing your speedometer
according to the wiring instructions, when the ignition is on it should immediately
display the default screen of 0 MPH, if the vehicle is not moving.
NOTE: You will then need to drive your vehicle to the predetermined measured
mile. During this trip, the speedometer should read something other than 0 MPH. If it
does not change, return and locate the problem before continuing. Otherwise,
proceed with the calibration.
2. Stop at the beginning of the measured mile with your vehicle running and in
odometer mode (NOT trip mode), press and hold the push-button until the odometer
displays 'HI- SP'. On its own, the gauge will then cycle through the recorded
performance in the following order: '0 – 60', '1/4', 'ODO', and 'CAL'.
3. While 'CAL' is displayed, quickly tap the push-button once. This will put the
speedometer in Program Mode. If you did not tap while 'CAL' is displayed, the
pulses per mile will be displayed on the odometer and the display will go back to
MPH mode. Otherwise, you will now see 'CAL' displayed along with the number '0'.
This indicates that the microprocessor is now ready for calibration.
4. When you are ready, begin driving on the metered mile. You will notice that the
reading will start counting. The odometer will begin to display the incoming pulse
count. Drive the vehicle through the measured mile (speed is not important, only the
distance traveled).
5. At the end of the mile, stop and press the push-button again. The odometer will now
display the new number of speedometer pulses that were registered over the distance.
The odometer will continue to display the pulse reading for a few seconds. Once it
reverts to the default mode, you have successfully calibrated your speedometer.
