1.3 Designated Use

This machine is intended for use engraving signs and other consumer products on applicable substrates. This laser can
process a wide variety of metals including steel, aluminium, titanium, brass, copper, tungsten, carbide, and chrome. It can
also be used with stone and some hard plastics such as acrylic. (See §§2.5 & 4.3 for further details.) Use of this system for
non-designated purposes is not permitted.
The system must be operated, maintained, and repaired by personnel familiar with the field of use and the dangers of the
machine and the material being engraved including its reflectivity, conductivity, potential for creating harmful or
combustible fumes, etc.
Laser beams are dangerous. The manufacturer and/or seller bear(s) no responsibility and assume(s) no liability for any
improper use of this device or for any damage or injury arising from such use. The operator is obliged to use this fiber
laser marker only in accordance with its designated use, the other instructions on the device and in its manuals, and all
applicable local and national laws and regulations.

1.4 Technical Specifications

Model
Input Power
Rated Power
Expected Service Life
Laser Wavelength
Laser Frequency
Processing Area
Max. Marking Speed
Min. Marking Depth
Max. Marking Depth
on a Single Pass
Min. Line Width
Precision
Required Operating
Environment
Required Operating Software
Dimensions
Net Weight
LYF-30BWc
220–240 V~ 50 Hz
30W
100,000 hr.
1064 nm
30–60 kHz
6.9×6.9 cm
700 cm/s
0.005 mm
0.08 mm
0.15 mm
±0.1 µm
Max. Humidity <70%
Temp. Range 5–35°C
EZCad
35×59×69.2 cm
30 kg
2
17.5×17.5 in.
275.6 ips
0.0002 in.
0.003 in.
0.006 in.
40–95°F
13.8×23.2×27.2 in.
66.1 lb.
