Console Operation

Desk settings

SCRIBBLE STRIP BRIGHTNESS
TFT BACKLIGHT BRIGHTNESS
TURN OFF DISPLAY AFTER
CONSOLE CHANNEL COUNT
The TFT and scribble strip displays can each be turned off by turning the control pot clockwise (beyond 8
NOTE. The following Automation options are only available if the console is rebooted into Legacy Automation mode.
Grouping
FADER GROUPING MODE:
GROUP LOCKOUT LEVEL:
Automation
GLIDE FRAMES:
ROLLBACK THRESHOLD FRAMES:
IN MIX SHOW:
MIX UPDATE MODE:
AUTOMATED SWITCHES TURN OFF ON: Select whether the off function of automatable switches is sent on the down-
2-44
Use this to adjust the channel scribble strip brightness (range: 1-6)
Use this to adjust the backlight level (range: 1 – 8)
Shuts off the TFT display after a predetermined time: 30 mins to 5 hours in 30
minute increments.
Should be set to the size of your console: 24, 48, 72 or 96. This setting
determines the range of channels selected by the Central Routing Panel's
ALL button.
or 6) to 'Off'.
Selects the fader grouping mode (Servo / VCA). (See GROUP CONTROL
FADERS for more details).
Set the group master level below which slave faders cannot have their balance
altered (available in Servo grouping mode only). The lockout level range is
–35dB to –70dB or OFF.
Sets the ramp time in frames for the automation SNAP mode. (range 0 – 255)
Sets the number of consecutive frames that the system needs to see to
determine if a Rollback has taken place. The range is 0 – 10; the default is 0
frames. Increase as required if a Rollback occurs when you stop the timecode
master.
Setting the threshold to 0 means that mix data can be entered in non real time
by setting the DAW nudge value to a frame, and using the nudge forward
command to step through the mix whist moving a fader or operating switch
functions. A reverse nudge command will automatically force a rollback,
returning the mix pass status to Mix Review and incrementing the rollback
counter.
When using the automation, you have a choice of what is displayed on the
consoles channel scribble strips (and below the Group and Master fader levels
in the Centre Section TFT screen). The choices are:
Automation Mode: displays the status of the faders – Auto, Safe or Manual;
Channel names in Mix running: displays the channel names once EXECUTE
is pressed in automation,
Channel names: displays the channels names regardless.
Sets the default automation mode at the start of an update mix (Replay /
Absolute / Trim).
press or release of the button (Press / Release).
