Automation

Snap Mode

Snap mode uses the fader touch sensor to control both the start and end of a fader update — for fast hands-on changes to
mix levels. When the fader is released, it ramps back to the previous mix level at a user-determined rate (see l e ra es),
then returns to Replay.
Snap mode can be overridden on any channel by pressing the fader button while still touching the fader knob. On releasing
the fader, the channel while stay in Absolute or Trim until a subsequent fader button press returns the channel to Replay. This
write/replay transition will include the ramped Snap glide if enabled in the setup menu (see l e ra es for more detail).

AutoTakeover

To avoid a level jump when dropping out of Write, AutoTakeover introduces nulling indication arrows to display the direction
to move the fader to match the underlying mix level. When AutoTakeover has been selected, these nulling indicators can
be displayed in the scribble strip for channel faders, and in the Centre Section TFT screen for Group and Master faders, by
pressing the channel's the fader status button. When the fader crosses the current mix level, it is automatically returned to
Replay and disconnected from the audio gain element. The fader returns to following the mix data as soon as it is physically
released.
O ne Tr
It is possible to trim the overall level of a channel fader without affecting the underlying automation data.To do this, press the
OFFLINE TRIM button in the AUTOMATION group, and use the channel V-pots to trim the channel gain. When a trim has
been introduced, the OFFLINE TRIM button flashes and the LED below the relevant V-pots lights. This level is stored and
can be recalled via the console TR setup, as described in Section 4.
To reset all Offline Trims to 0 dB, press and hold the OFFLINE TRIM button. To reset individual channels to 0 dB push the
V-pot switch.
