DAW
Send Mode
Select the SEND button on the Master Control Panel, and the V-pots become level controls for any sends or aux
send levels within the DAW.
The Master V-pot (2) selects which of the available sends (A – E or 1 – 5) is being controlled by the channel
V-pots. The selected send is shown in the display window above the Master V-pot (and on the channel V-pot
scribble strip). The channel scribble strips show the name of the currently selected send. Turning a channel
V-pot will alter the level of the selected send from that channel. Holding down the ALT button allows you to make
fine adjustments to the gain. See over the page on how to use faders to set send levels.
Setting Sends Pre/Post Fader
When working with sends it is useful to be able to flip a send between pre and post fader. If necessary, first select
the PRE/POST button (4) on the Master Control Panel. Pushing a channel V-pot will now switch the selected
send on that channel between pre and post. The green LED below the V-pot lights to show PRE is selected.
To change mode on all channels, press and hold the Master Control Panel OPTION button then press any
channel V-pot. All channels will switch to pre or post.
Muting a Send Output
To mute a send output, select the MUTE button (4) on the Master Control Panel and push the channel V-pot. The
LED below the channel V-pot will light to show the channel is muted. To mute or un-mute all channels, press and
hold the OPTION button then press any channel V-pot.
Flipping Send Levels to the Faders
To flip send levels from the V-pots to the channel faders, press the Master V-pot (2) — hence Push to Flip! The
channel faders now control send levels and the fader CUT button will mute a send. The channel V-pot controls
panning on stereo sends.
In this 'flipped' mode, PRE/POST mode is automatically selected for the V-pot switches, so pushing a V-pot will
toggle the send pre/post on that channel. The LED below the V-pot lights to show PRE is selected.
Note that the fader SOLO button will still solo the channel, not the send.
