DAW

DAW Utility Buttons (9)

This group of four buttons provide shortcuts to useful functions on the DAW.
SAVE will light when unsaved data is present. Pressing it once will cause the SAVE button to flash. A second
press will save the Pro Tools session. Press ESC to cancel a pending save.
The UNDO button will light if undo is available, and flash if redo is available. Press the UNDO button to undo the
last function and press ALT + SHIFT + UNDO to redo the last function.
ENTER duplicates the function of the ENTER key on the computer keyboard.
ESC(ape) duplicates the function of the ESC key on the computer keyboard.
1
CHANNEL

Modifier Buttons (10)

These buttons modify the function of other buttons, and their practical use is detailed under the relevant topics
in this section. For your information:
OPTION typically changes the function of a single button to affect all similar buttons.Thus holding down OPTION
and pressing a channel CUT button will cut all DAW channels. It is a direct equivalent of a current Mac keyboard
Option (⌥) key. The additional alt label found on this key refers to its use in Unix and Windows environments.
SHIFT allows selection of multiple objects or controls. It is a direct equivalent of the computer keyboard shift key.
ALT increases the resolution of rotary controls and inverts switch selections when held down. It is the direct
equivalent of the Command (⌘) key on a current Apple keyboard.
CTRL disengages grouping when held down. It is a direct equivalent of the Mac keyboard Ctrl key.
Although on the surface confusing, the OPTION and ALT keys are labelled according to the definitions in the Pro
Tools HUI operating instructions which correspond to key cap labels on legacy mac keyboards. We have retained
this convention to avoid confusion when following the many modifier key short cuts documented in the Pro Tools
guide to MIDI controllers.
3-8
3
SEND INPUT
2
OUTPUT
ASSIGN
PAN
Push to Flip
5
RDY EDIT SEL
6
CHANNEL
4
MUTE UNDO SAVE
9
PRE/
ESC ENTER
POST
BYPASS OPTION
SHIFT
10
7
DEFAULT
CTRL ALT
SUSPEND
RDY
AUTO ALL
12
8 11
ALT
STATUS
TRANS
13
MEM
MIX
EDIT
