Components

To use your HP iPAQ to its full potential, identify components and learn about its functions.

Front panel components

Component
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
iPAQ
Description
Proximity Sensor
Light Sensor
Receiver
Touch-screen Display
QWERTY Keyboard
End/Power Key
ok Key
5-Way Optical Navigation with
Center Select button
Function
This component detects when the phone is in use, and then locks the
screen and turns off the screen backlight.
This component sets the keyboard backlight to the ambient light
settings as per the surrounding light conditions.
Use to listen to phone calls, sounds, and notifications.
Use to view the on-screen contents. Use the stylus to select items,
navigate menus, change feature settings, and play games.
Use keys on the keyboard to enter text or dial numbers.
NOTE: The keyboard layout might vary depending on the country/
region.
Press to end a phone or data call.
Press and hold for 1 second to put your HP iPAQ into suspend mode,
or to wake it up if it is already in suspend mode.
Press and hold for 5 seconds to turn on and off the HP iPAQ.
Press to confirm your selection, click the ok button, or click the close
window icon in the upper-left corner of the screen.
Navigate up, down, left, and right on the screen with the 5-way optical
navigation. Scroll by sliding your thumb or finger in the direction you
want.
Press the Center Select button to select the item highlighted on the
screen.
