SmartHandle AX Advanced Metal frame
12
PH2
5. For door thickness X: prepare the spindle
*X
13
*X
14
Abbildungen/Images
Door thickness + 50 mm (±2 mm)
5. For door thickness X: prepare the spindle
7 / 56
