Installing The Fitting - Simons Voss Technologies SmartHandle AX Advanced Series Quick Manual

5. For door thickness X: prepare the spindle
1. Remove the mortise lock.
2
2. Measure the distance (gap between the spindle and cylinder axes of ro-
tation).
3
3. Fit the mortise lock.
4
4. Insert the spindle into the mortise lock.
5
5. Place the drilling template on the spindle from the inner side.
6
6. Align the drill template vertically using the printed scale.
7. Mark the points to be drilled on the door.
7
8. Remove the drilling template and spindle.
8
9. Remove the mortise lock.
2
10. Drill the required holes (bottom hole is only required on the inner side).
10
11. Deburr drilled holes with a countersink.
11
12. Fit the mortise lock.
12
5. For door thickness X: prepare the
spindle
ü Saw at hand.
ü Caliper gauge at hand.
1. Measure the door thickness.
13
2. For X: mark the sawing point on the spindle.
14
3. For X: Trim the spindle with a suitable saw.
15

6. Installing the fitting

ü Door pre-drilled.
ü Blind rivet nut pliers at hand.
ü PH2 screwdriver at hand.
ü TX15 screwdriver at hand.
ü Caliper gauge at hand.
1. Fit the blind rivet nuts into the pre-drilled holes.
16
2. For non-MO: insert the blank cylinder.
NOTE
Feed the blank cylinder into the hole using a screwdriver
It is difficult to position the blank cylinder correctly, especially in thick doors.
1. Insert a screwdriver into the hole in the blank cylinder.
2. Position the blank cylinder using the screwdriver.
17
18
32 / 56
SmartHandle AX Advanced Metal frame
3. For non-MO: screw the blank cylinder firmly into position.
19
4. Use the 12 mm screws to fix the fastening plate onto the outer side of
the door (PH2) with the tip facing upwards.
20
21
5. Insert the module support into the fastening plate.
22
6. Slide the module support upwards.
23
9 Module support snaps into place.
7. Use the 18 mm screws to fix the module support onto the fastening
plate (PH2).
24
25
8. Place the cover on top of the fastening plate.
26
9. Fold down the cover.
27
10. Push the cover against the door, sliding it upwards at the same time.
28
9 Cover snaps into place.
11. Press the inlay into place.
29
12. Fit the outside handle.
30
13. Determine the required direction of rotation for your inside handle.
14. Insert the spring element appropriately.
15. Place the underlay in the inside handle unit.
31
32
16. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre
of the spindle. Use a punch and hammer to make an indent in the ad-
apter sleeve to prevent it from slipping.
33
34
17. Measure the total length of the spindle.
35
18. Locate the inside of the spindle (four-edge end up to the centre of the
first groove = 26 mm).
19. Use the table to determine the position of the O-ring.
36
