SmartHandle AX Advanced Metal frame
Door thickness
Area
(mm)
S 38 – <42
S 38 – <42
S 42 – <47
S 42 – <47
S 47 – <52
S 47 – <52
S 52 – <57
S 57 – 60
M 58 – <62
M 58 – <62
M 62 – <67
M 62 – <67
M 67 – <72
M 67 – <72
M 72 – <77
M 77 – 80
L 78 – <82
L 78 – <82
L 82 – <87
L 82 – <87
L 87 – <92
L 87 – <92
L 92 – <97
L 97 – 100
XL 98 – 184
20. Slide the O-ring onto the calculated groove.
37
21. Insert the spindle into the door with the ring-free side as far as it will go.
38
22. Place the inside handle unit on the spindle.
39
23. Use the 22 mm screws to fasten the inside handle unit onto the inner
side of the door (PH2).
40
41
24. Use the 16 mm screws to fasten the cylinder escutcheon on the inner
side of the door (PH2).
42
43
25. Use the grub screws to tighten both handles (TX15).
44
26. Place the cylinder plate and the inside handle cover onto the escut-
cheons.
45
9 SmartHandle AX Advanced fully installed.
7. Removing the fitting (metal frame)
1.5 mm hexagonal wrench available.
ü
EN
Spindle length
Ring position
(mm)
94 3
104 5
94 2
104 4
94 1
104 3
104 2
104 1
114 3
124 5
114 2
124 4
114 1
124 3
124 2
124 1
134 3
144 5
134 2
144 4
134 1
144 3
144 2
144 1
O-ring is 30–35 mm from the cut
end of the spindle.
7. Removing the fitting (metal frame)
1. Insert a flat-head screwdriver (ideally angled) into the opening in the
lower surface of the panels on the inside.
46
2. Lever off the panels with the flat-head screwdriver.
47
3. Remove the fitting in the reverse order to installation.
4. Loosen the cover by bending the inlay outwards using the special tool.
5. Insert a 1.5 mm hex key into the hole in the spindle mount in the module
support.
48
6. Bend the hex key to the side where the hole is located while pulling on
the outside handle.
49
9 SmartHandle AX Advanced is now removed.
8. Replacing the batteries
NOTE
Malfunctions due to poor contact or different discharge
Contact surfaces that are too small/contaminated or different discharged
batteries can lead to malfunctions.
1. Only use batteries that are approved by SimonsVoss.
2. Do not touch the contacts of the new batteries with your hands.
3. Use clean and grease-free gloves.
4. Always replace all batteries at the same time.
Special tool at hand.
ü
Gloves at hand.
ü
1. Insert the special tool into the cover inlay on the electronics side.
50
2. Use the special tool to carefully bend the cover inlay upwards.
51
3. Slide the cover downwards.
52
Cover unlocked.
9
4. Remove the cover.
53
5. Use the special tool to detach the battery module clip.
54
6. Remove the battery module.
55
7. Use the special tool to detach the battery clip.
56
8. Remove the upper batteries.
57
9. Carefully bend the intermediate spring to one side.
10. Remove the lower batteries.
58
11. Insert two new batteries with the positive terminals next to each other
(type CR2450).
59
9 Intermediate spring visible above the lower batteries.
12. Insert two new batteries with the positive terminals next to each other
(type CR2450).
60
13. Reattach the battery clip.
61
