New Generation Digital Infrared Wireless Conference System

Installation and Operating Manual
V 2.16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCS-5300/80 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Taiden HCS-5300/80 Series

Summary of Contents for Taiden HCS-5300/80 Series

  • Page 1 New Generation Digital Infrared Wireless Conference System  Installation and Operating Manual V 2.16...
  • Page 2 To protect your hearing avoid high pressure level on earphones. Adjust to a lower and convenient level.  If any detailed information needed, please contact your local agent or TAIDEN service center in your region. Any feedback, advice and suggestion about the products is appreciated.

  • Page 3: Important Safety Instructions

    TAIDEN Service Center. splashing and that no objects filled with liquids, such as 20. All TAIDEN products are guaranteed for definite time vases, shall be placed on the apparatus. (see the WARRANTY CARD for details) excluding the...
  • Page 4 Important Safety Instructions WARNING: To reduce the risk of electric shock, DO NOT expose units to rain or moisture. Attention: Installation should be performed by qualified service personnel only in accordance with the National Electrical or applicable local codes. Power Disconnect: Units with or without ON – OFF switch have power supplied to the unit whenever the power cord is inserted into the power source;...

  • Page 5: Lithium Battery Safety Precautions

    Lithium battery safety precautions  To change battery please power off and take off the battery immediately.  Keep the battery away from heat sources to prevent fire or explosion.  Do not use a battery that is leaking, deformed, discolored or overheats. ...

  • Page 6: Table Of Contents

    Contents Installation & User Guide ......................IX Chapter 1 System introduction ....................1 1.1 Overview ..................................1 1.2 Functions and features ..............................5 1.3 System technology ..............................6 1.3.1 Basic system concept ..............................6 1.3.2 IR radiation .................................. 6 1.3.3 Carriers and channels ..............................6 1.4 Aspects of infrared signal transmission ........................
  • Page 7 2.5.12 Mic. Auto Off ................................34 2.5.13 Language ................................35 2.5.14 Network Setting ............................... 35 2.5.15 Time Setting ................................35 2.5.16 Video Tracking ................................. 35 2.5.17 Mute Speaker ................................35 2.5.18 Alarm Setting ................................36 2.5.19 Backup/Restore ............................... 36 2.5.20 Voice Mode Setting ..............................36 2.5.21 WiredMic Function ..............................
  • Page 8 3.6 Connecting to main unit ............................. 72 3.7 Technical data ................................73 Chapter 4 Digital infrared wireless conference unit ..............75 4.1 HCS-5300/80 Series ..............................75 4.1.1 Overview ................................... 75 4.1.2 Functions and indicating ............................76 4.1.3 Infrared service area ..............................79 4.1.4 Precautions in using ..............................
  • Page 9 5.2.3 CMU setting ................................116 5.2.4 Video matrix ................................117 5.2.5 Predefined position..............................119 5.2.6 S.I. setup ................................. 120 Chapter 6 Accessories ......................122 6.1 Digital IR conference room switcher ........................122 6.1.1 HCS-5300MX ................................122 6.1.2 HCS-5300MX/20 ..............................127 6.2 Lithium battery .................................

  • Page 10: Installation & User Guide

    About this manual This manual is a comprehensive guide to the technical data of peripheral equipment and accessories installation and operation of TAIDEN HCS-5300/80 for Digital IR Conference Room Switcher, batteries, new generation digital infrared wireless conference charging devices, power adapter and earphones.
  • Page 11 Installation & User Guide This manual is applicable to: HCS-5302C/80  Digital IR Wireless Conference System Main Digital IR Wireless Chairman Unit (discussion) Unit HCS-5302D/80 HCS-5300MA/80A Digital IR Wireless Delegate Unit (discussion) Digital IR Wireless Conference System Main Unit HCS-5380CVS (discussion, voting, 1+7 CHs, with interface for Digital IR Wireless Chairman Unit (discussion, voting, HCS-4100/50...
  • Page 12 Installation & User Guide  Software HCS-5390RCAE Digital IR Wireless Chairman Unit (discussion, voting, HCS-5300WS Web control Software (CMU setting, microphone 1+7 CHs, rectangular columnar metal microphone, control, video matrix, S.I. setting) Ø16mm gold-plated large-diaphragm high performance electret condenser microphone, Braille, modern gray, excl.
  • Page 13 Installation & User Guide CBL5300-30 30 m Dedicated Transceiver Cable CBL5300-40 40 m Dedicated Transceiver Cable CBL5300-50 50 m Dedicated Transceiver Cable CBL5300-05CMP 5 m Dedicated Transceiver Cable (CMP) CBL5300-10CMP 10 m Dedicated Transceiver Cable (CMP) CBL5300-20CMP 20 m Dedicated Transceiver Cable (CMP) CBL5300-30CMP 30 m Dedicated Transceiver...

  • Page 14: Chapter 1 System Introduction

    Chapter 1 System introduction 1.1 Overview TAIDEN HCS-5300/80 series product is a digital The system consists of one digital infrared wireless infrared wireless conference system convenient for conference main unit, one or more digital infrared mobile use as well as for permanent installations. The...
  • Page 15 The system is composed of one or more of the following:  Digital IR Wireless Conference System Main HCS-5302C/80 Unit Digital IR Wireless Chairman Unit (discussion) HCS-5302D/80 HCS-5300MA/80A Digital IR Wireless Delegate Unit (discussion) Digital IR Wireless Conference System Main Unit HCS-5380CVS (discussion, voting, 1+7 CHs, with interface for Digital IR Wireless Chairman Unit (discussion, voting,...
  • Page 16 HCS-5390RCAE Web control Software (CMU setting, microphone Digital IR Wireless Chairman Unit (discussion, voting, control, video matrix, S.I. setting) 1+7 CHs, rectangular columnar metal microphone, Ø16mm gold-plated large-diaphragm high performance  Digital IR Conference Room Switcher electret condenser microphone, Braille, modern gray, HCS-5300MX Digital IR Conference Room Switcher excl.
  • Page 17 CBL5300-20 20 m Dedicated Transceiver Cable CBL5300-30 30 m Dedicated Transceiver Cable CBL5300-40 40 m Dedicated Transceiver Cable CBL5300-50 50 m Dedicated Transceiver Cable CBL5300-05CMP 5 m Dedicated Transceiver Cable (CMP) CBL5300-10CMP 10 m Dedicated Transceiver Cable (CMP) CBL5300-20CMP 20 m Dedicated Transceiver Cable (CMP) CBL5300-30CMP 30 m Dedicated Transceiver...

  • Page 18: Functions And Features

    1.2 Functions and features 1. Digital infrared wireless conference system 5. Full functions operating TAIDEN dirATC technology - digital Discussion infrared Audio Transmission Control Vote (3 or 5 keys) technology Simultaneous interpretation (1+7 channels) Isolated audio recording function for simultaneous interpretation (1+7 channels) 2.

  • Page 19: System Technology

    The system composition of HCS-5300/80 digital infrared wireless conference system is shown in figure 1.3.3 Carriers and channels 1.2. It is composed of:  Digital infrared wireless conference units for TAIDEN HCS-5300/80 digital infrared wireless participators conference system adopts 1~8 MHz wave band (IEC ...

  • Page 20: Aspects Of Infrared Signal Transmission

    1.4 Aspects of infrared signal transmission 1.4.2 Objects, surfaces and reflections To benefit from the advantages of a digital infrared wireless conference system the signals should be Just like visible light, infrared radiation is reflected from transmitted undisturbed. This is achieved by using hard surfaces and refracted by hyaloid (glassy or digital infrared transceivers well positioned and transparent...

  • Page 21: Infrared Service Area Of Digital Infrared Wireless Conference Unit

    1.4.3 Infrared service area of digital infrared wireless conference unit Infrared light is directional invisible light. Infrared HCS-5380 or HCS-5390 series digital infrared wireless wireless conference unit gets best sensitivity when it conference unit is equipped with infrared glass at its directly faces a transceiver.

  • Page 22: Infrared Service Area Of Digital Infrared Transceiver

    1.4.4 Infrared service area of digital infrared transceiver The type of the digital infrared transceiver determines position of the infrared wireless conference unit. The the covering area. More transceivers can enlarge the size and the position of the coverage area are related covered area.

  • Page 23: Overlap And Multipath Effects

    1.4.5 Overlap and multipath effects If footprints of two transceivers overlap, its total coverage area may be larger than the sum of the two separate footprints. In an area with overlap effect, the individual radiation signals of two transceivers are added, resulting in an increase of the radiation intensity, larger than the required intensity.

  • Page 24: System Specification

    1.5 System specification 1.6 Connection details  System performance Mains cables Conforms to the international standard ISO 22259 Blue Neutral The carrier frequency (0~3) transmitted by the main Brown Live unit conforms to IEC 61603-7, the international Green/Yellow Earth/Ground standard for digital infra-red transmission of audio signals for conference and similar applications.

  • Page 25: Chapter 2 Hcs-5300M/80A Series Digital Ir Wireless Conference

    Chapter 2 HCS-5300M/80A Series Digital IR Wireless Conference System Main Unit 2.1 Overview HCS-5300M/80A digital infrared wireless conference HCS-5300MC/80A system main unit is the heart of the HCS-5300/80 Digital IR Wireless Conference System Main Unit wireless conference system. The main unit can be (discussion) connected to digital infrared transceivers and recording devices and:...

  • Page 26: Functions And Indications

    2.2 Functions and indications Front panel of HCS-5300M/80A main unit Rear panel of HCS-5300MA/80A main unit Rear panel of HCS-5300MB/80A main unit Rear panel of HCS-5300MC/80A main unit Figure 2.1 Digital infrared wireless conference system main unit 1. Standby key Dante network to transmit audio signals.
  • Page 27 6. A type USB interface  To plug-in a USB stick. 7. Mini USB interface  For connecting to PC. 8. RS-232C port  Used for connecting to a central control system for central controlling, as well as for system diagnosis.

  • Page 28: Installation

    2.3 Installation HCS-5300M/80A series digital infrared wireless conference system main unit can be fixed in a standard 19-inch cabinet. Put the main unit in the cabinet and fix the four holes up with screws ①. Figure 2.2 Installation of digital infrared wireless conference system main unit In addition, 1U metal stripes are included as decoration to be installed between the main units in the cabinet.

  • Page 29: Connection

    2.4 Connection Several typical system connections of HCS-5300M/80A series main unit will be introduced in this section, including connection:  To other auxiliary devices  To interpretation devices  To HCS-8300MI series  System connection [Wired/wireless discussion + digital simultaneous interpretation + voting + video tracking] ...

  • Page 30: To Hcs-8300Mi Series

    2.4.3 To HCS-8300MI series HCS-5300M/A main unit connect with HCS-8300MI series for example for remote interpretation purposes or for 8 Channels Audio Input Interface to realize the following transmission to floor channel function: b) All inputs can be mixed with arbitrary ratio, and a) Transmits 7 digital (AES/EBU)/analog audio channels outputted to any channel;...

  • Page 31: To Hcs-8600Mio Series To Realize Audio Input And Output

    2.4.4 To HCS-8600MIO series to realize audio input and output HCS-5300M/A main unit connect with HCS-8600MIO Connect to audio output devices such as recording series audio input and output device to realize the equipment or speakers for audio output. following functions: Input digital (AES/EBU)/analog audio signals to the translation channel of the conference system to achieve off-site simultaneous interpretation...

  • Page 32: To Hcs-8600Mio Series And Hcs-8685Bm To Realize Booth Borrow Funciton

    Audio Input & Output Device and HCS-8685BM are in the same network, interpreter booths can be Booth Manager to realize booth borrow function by assigned to the conference rooms while keeping the line TAIDEN Booth Management System via network. connection unchanged through...

  • Page 33: System Connection 1

    2.4.6 System connection 1  [Wired/wireless discussion + digital simultaneous interpretation + voting + video tracking] HCS-5300MA/80A has the functions for discussion, high-speed dome camera. vote and digital simultaneous interpretation. The Use a RS-485 cable and connect the HCS-5300M/80A system can be connected to an automatic video main unit (port “TO VIDEO SWITCHER”) to the tracking system.
  • Page 34 Figure 2.11 System connection [Wired/wireless discussion + digital simultaneous interpretation + voting + video tracking]...

  • Page 35: System Connection 2

    LAN or internet. The automatic video tracking system is compatible with If using TAIDEN network central control system touch several kinds of video signals and operates automatic panel to control conference units, the ID of each video switching.
  • Page 36 Figure 2.12 System connection [Wired/wireless discussion + digital simultaneous interpretation + video tracking + central control]...

  • Page 37: System Connection 3

    The automatic video tracking system is through LAN or internet. compatible with several kinds of video signals and If using TAIDEN intelligent central control system touch operates automatic video switching. The video tracking panel to control conference units, the ID of each...
  • Page 38 Figure 2.13 System connection [Wireless discussion + video tracking + central control]...

  • Page 39: Load Capacity

    2.4.9 Load capacity HCS-5300MA/MB/80A main unit can connect to and power for digital infrared wireless transceiver, wired congress unit and interpretation unit. So, devices type and quantity must be considered synthetically when designing a system (Table 2.1).  The HCS-5300MA/80A or HCS-5300MB/80A main unit can connect to 10 HCS-5300TD/80 or HCS-5300TH/80 transceivers,...

  • Page 40: Configuration And Operation

    2.5 Configuration and operation B ) Access main menu Digital infrared wireless conference system main unit can be configured and set up through menu operation with Pressing the operation knob under initial interface will go four buttons. All menu items operation will be introduced to main menu, which includes the following items: one by one in this section.

  • Page 41: Audio Mode Setting

    2.5.1 Audio Mode Setting “Audio Mode” includes three submenus: “Normal”, “Remote Conferencing” and “External Process”.  Normal: LineOut1/2 and floor audio output feature each the sum signal of Dante In + LineIn1 + LineIn2 + active microphones (figure 2.12);  Remote Conferencing: Rotate the operation knob to select audio mode;...
  • Page 42 Figure 2.13 Audio mode setting – Remote Conferencing Mode1 Figure 2.14 Audio mode setting – Remote Conferencing Mode2...
  • Page 43 Figure 2.15 Audio mode setting – External Process Mode1 Figure 2.16 Audio mode setting – External Process Mode2...

  • Page 44: Operation

    2.5.2 Operation 2.5.4 System Status Rotate the operation knob to switch microphone mode Rotate the operation knob to select “Carrier Using among “Open”, “Override” and “Voice”. Status” and press the knob to confirm. The status of every channel and the status of the active microphone(s) and their batteries will be displayed.
  • Page 45 go to step b). in another booth to override an occupied channel in another booth, but supplying the b) Select Language of Channel same channel.  “OVERRIDE-BC” mode enables A/B/C channel of an interpreter unit in another booth to override an occupied B/C channel in another booth, but supplying the same channel;...

  • Page 46: Line In 1 Setting

    f) Distribute Floor to Used SI Channel 2.5.8 Headphone Auto Att. Enable/disable switch to floor channel automatically when no interpretation channel is available. If a headphone is plugged, howling may happen when the microphone is activated. “Headphone Auto Att.” 1). Rotate the operation knob to select “Yes” or “No”; function is used to suppress howling for floor language 2).

  • Page 47: Mic. Parameters

    microphones will resume. 2. “Mic. Low Cut Setting”  “All Off”: when the chairman presses the “Priority” button, all active microphones will be deactivated. 2.5.11 Mic. Parameters a). Rotate the operation knob to select “On” or “Off”; b). Press the knob to save and return to the upper level menu.

  • Page 48: Language

    2.5.13 Language 2.5.15 Time Setting a). Rotate the operation knob to switch language from Rotate the knob to switch between the four “中_简”, “中_繁”, “English”; numbers; b). Press the knob to confirm and return to the upper Press the knob to edit the selected number; level menu.

  • Page 49: Alarm Setting

     If “Yes” is selected, the loudspeaker is muted when c). Return to the upper level menu after backup or the headphone is plugged; reboot the main unit after recovery to save the  If “No” is selected, the loudspeaker and the parameters.

  • Page 50: Wiredmic Function

    2.5.21 WiredMic Function Enable/disable WiredMic function. b). Turn the primary knob to select a number (1-6), and press the ‘B’ button to confirm; c). Press the knob to stop numbering and return to a) Rotate the operation knob to select “Yes” or “No”; upper level menu.

  • Page 51: Usb Audio Setting

    2.5.24 Mic. Led Setting Set up the color of indicator lamp rings when turn on the microphone and the “ON/OFF” button. a) Insert the U-disk and the Web Server process well be installed automatically. “Success” will be displayed on the LCD if the installation successful. b) Reboot the main unit to enable Web Server.

  • Page 52: Line Out1 Noise Gate

    a). Rotate the operation knob to select “No” or “Yes”; c). Rotate the operation knob to set sync number from b). Press the knob to confirm the operation and return to 1 to 4; the upper level menu. d). Press the knob to confirm the operation and return to the upper level menu.

  • Page 53: One Touch Turn On

    a). Rotate the operation knob to select “On” or “Off”. a) Rotate the operation knob to select “Enable” or Settings for “On”: No output for channel C; “Disable”; b). Press the knob to confirm the operation and return to b) Press the knob to save and return to the upper level the upper level menu.

  • Page 54: Transceiver Power

    a). Rotate the operation knob to select extend mode b). Press the knob to save and return to the upper level between "Master" and "Slave" : menu.  If select " Master ", press the operation knob to save and jump to step b); 2.5.42 Sampling Rate Setting ...

  • Page 55: About Dante

    upper level menu. Note:  When power down the main unit, please press and hold the standby key to enter power management interface, then select “Power Off” and press the operation knob to confirm. Please do not use the switch button on the back of the 2.5.45 About Dante main unit to shutdown directly;...

  • Page 56: Usb Audio

    2.6 USB Audio HCS-5300M/A has a built-in USB Audio (1 channel, 16bit, 32kHz) which can be connected to the computer through USB cable (software requirement: WindowsXP or higher) for digital audio input/output when the “USB Audio Setting” of main unit is enable. We take Win7 system as an example to introduce the function and operation of the USB Audio. 2.6.1 Installation of USB Audio Once the HCS-5300M/A main unit connects to the computer, the HCS-5300M USB Audio will be detected and activated automatically instead of the default audio device.

  • Page 57: Digital Audio Input

    2.6.2 Digital audio input When the HCS-5300M/A main unit is connected to the computer, the conference units connected in the system are the microphone for digital audio input. Using the recording software or the third party communication software, such as recorder, Skype or QQ and so on, functions like recording, remote instruction, remote communication can be implemented.

  • Page 58: Digital Audio Output

    2.6.3 Digital audio output The HCS-5300M/A main unit can be connected to the computer for digital audio output. Please adjust and test the HCS-5300M UBS Audio to a suitable volume when first using. Adjust method: open the control panel-sound (or right click the volume icon on the taskbar and select sound), and select the speakers (HCS-5300M UBS Audio) and modify its setting in the Playback dialog box, as shown in the following figure: Figurer 2.19: Adjusting playback volume...

  • Page 59: Technical Data

    2.7 Technical data Type HCS-5300MA/80A HCS-5300MB/80A HCS-5300MC/80A √ √ √ Discussion Simultaneous interpretation Max. (1+7) channels Max. (1+7) channels √ Vote √ Dante Mains voltage AC 100V-240V 50Hz/60Hz Power consumption 30 W 25 W Power Capacity Max.500W Max.200W LINE IN 1: +10 dBu, balanced, XLR socket Audio inputs LINE IN 2: +15 dBu, unbalanced, RCA jack LINE OUT 1: +20 dBu, balanced, XLR socket...

  • Page 60: Chapter 3 Digital Infrared Transceiver

    Chapter 3 Digital infrared transceiver 3.1 Overview digital infrared transceiver manages communication between main unit conference units. It can be mounted onto the ceiling or the wall for optional coverage or fixed onto a tripod at any appropriate spot. Types： HCS-5300TD/80 Digital Infrared...

  • Page 61: Functions And Indications

    3.2 Functions and indications 3.2.1 Digital infrared transceiver HCS-5300TWN Digital infrared transceiver Figure 3.1 HCS-5300T digital infrared transceiver HCS-5300TD Digital infrared transceiver Figure 3.1: 2-meter 6 PIN cable CBL-5300 Power indicating light Switchers for radiation area selection Note:  The HCS-5300TDS/80 digital infrared...

  • Page 62: Digital Infrared Cable Splitter

    3.2.2 Digital infrared cable splitter HCS-5352 digital infrared cable splitter with one input and four outputs that can be used to connect four transceivers/ receivers at most. Figure 3.2 HCS-5352 cable splitter Figure 3.2: 1. To the transceiver interface of the main unit 2.

  • Page 63: Infrared Service Area

    3.3 Infrared service area a.HCS-5300TD(S)/80 b.HCS-5300TH/80 Mounting Coverage area Type No. height (H) radius (R) 2.5 ~ 3.0 m 13 m HCS-5300TD/80 3.5 ~ 4.5 m 11 m HCS-5300TDS/80 5.0 ~ 7.0 m 6.0 m HCS-5300TH/80 9.0 m 11 m 12 m Mounting Coverage area...

  • Page 64: Position Planning

    3.4 Position planning 3.4.1.2 Stay away from lighting equipment 3.4.1 Precautions in planning the digital infrared transceiver/receiver Although HCS-5300 system has good anti-interference performance to ambient light, the distance of the Due to strict demands on intensity and stability of transceiver/receiver from lighting equipment must be at infrared signals in an infrared wireless conference least 50 cm to guarantee adequate intensity and stability...
  • Page 65 3.4.1.4 Make each conference unit communicating with more than one transceiver As shown in the following figure: when the speaker in the front row speaks in an upright position, the infrared signal will be blocked. In conference rooms with conference units in rows, each conference unit should communicate with more than one transceiver to avoid blocking.

  • Page 66: Planning Digital Infrared Transceiver

    3.4.2 Planning digital infrared transceiver The coverage area of the digital infrared transceiver is defined by the distance between the transceiver and the conference unit. Select suitable transceiver type according to the height of the conference room, locate them at reasonable positions and place all conference units within the coverage area.
  • Page 67 3.4.2.2 Example for planning the transceiver 【Square table arrangement】 【Rectangular table arrangement】 If the transceivers are arranged as shown in the following Generally: conference rooms with identical figure, the coverage area of infrared signals will cover dimensions, position transceivers the entire meeting room. determined by the arrangement of the conference units (Figure 2.14 to 2.17) The following figures show the ideal position planning of...
  • Page 68 A) Conference style seating (circulatory seating) could only communicate with the few conference units in the last row (left row in Figure 3.16), compared to the Within the circulatory seating operating area of the transceiver placed over the front row. The reason is that conference units, the transceivers must be placed evenly.

  • Page 69: Planning The Path From Main Unit To Transceiver

    3.4.3 Planning the path from main unit to 【Balcony venue】 transceiver In a balcony venue, with a higher ceiling and the shielding from the gallery, the transceiver planning must depend on 3.4.3.1 Cautions for cable connecting the height of the ceiling and the style of seating. For ...
  • Page 70 3.4.3.2 Using distributor If using distributors, do not use more than one distributor in one branch, or it will increase high frequency signal loss and may cause system fault. Connections to transceivers with and without distributors in the branch, cannot work together in one system. When installed in several rooms, the cable splitter must be connected to the main unit directly and the cable lengths to different rooms do not need to be equal, as shown in...

  • Page 71: Installation

    3.5 Installation 3.5.1 Installation of HCS-5300TD/80 3.5.1.1 Ceiling mounted 1 ① HCS-5300TD/80 digital infrared transceiver ② HCS-5300TD/80 digital infrared transceiver ceiling-mounting kit ③ Mounting hole (drilled on the ceiling) ④ Ceiling Figure 3.21 HCS-5300TD/80 digital infrared transceiver ceiling mounted Mounting steps: Step 1: Install the ceiling mounting kit at the top of the HCS-5300TD/80 Transceiver;...
  • Page 72 3.5.1.2 Ceiling mounted 2 ① PA3 self-tapping screws ② Hard ceiling mounting bracket ③ Rubber plug ④ Hard ceiling (such as concrete ceiling) ⑤ HCS-5300TD/80 digital infrared transceiver Figure 3.22 HCS-5300TD/80 digital infrared transceiver ceiling mounted Mounting steps: Step 1: Position the mounting bracket on the ceiling according to the installation location of the HCS-5300TD/80 and mark the positions of the drilling holes.
  • Page 73 3.5.1.3 Tripod mounted (Adjustable angle) ① HCS-5300TD/80 digital infrared transceiver ② M3 screw ③ Wall-mounted bracket (with flexible tube) ④ Tripod-mounted stator ⑤ HCS-5300TZJ2 (should be ordered separately) Figure 3.23 HCS-5300TD/80 digital infrared transceiver tripod mounted Mounting steps: Step 1: Fix the HCS-5300TD/80 digital infrared transceiver onto the wall-mounted bracket with M3 screws;...
  • Page 74 3.5.1.4 Tripod mounted ① Hard ceiling mounting bracket ② HCS-5300TD/80 digital infrared transceiver ③ HCS-5300TZJ2 (should be ordered separately) Figure 3.24 HCS-5300TD/80 digital infrared transceiver tripod mounted Mounting steps: Step 1: Put the bracket on the bottom of the transceiver and fix it with rotation; Step 2: Aim the mounting hole at the bottom of HCS-5300TD/80 digital infrared transceiver to the screw on the tripod;...
  • Page 75 3.5.1.5 Wall mounted (Adjustable angle) ① HCS-5300TD/80 digital infrared transceiver ② M3 screw ③ Wall-mounted bracket (with flexible tube) ④ PA3 self-tapping screws ⑤ Wall Figure 3.25 HCS-5300TD/80 digital infrared transceiver wall mounted Mounting steps: Step 1: Fix the HCS-5300TD/80 digital infrared transceiver onto the wall-mounted bracket with M3 screws;...

  • Page 76: Installation Of Hcs-5300Tds/80

    3.5.2 Installation of HCS-5300TDS/80 ① M6×60 hook up riveting bolt (Standard hardware accessories, self-purchased by customer) ② M4 screw（M4×40）and nut ③ User customized suspension (see figure 3.30 for requirements) or HCS-5300TDP suspension (optional length) ④ M3×12 screw ⑤ Hard ceiling (such as concrete ceiling) Figure 3.26 HCS-5300TDS/80 digital infrared transceiver suspension mounted Mounting steps: Step 1: Fix M6×60 hook up riveting bolt onto the hard ceiling (such as concrete ceiling);...
  • Page 77 Figure 3.27 Requirements of user customized suspension...

  • Page 78: Installation Of Hcs-5300Th/80

    3.5.3 Installation of HCS-5300TH/80 3.5.3.1 Ceiling mounted ① HCS-5300TH/80 digital infrared transceiver ② HCS-5300TH/80 digital infrared transceiver ceiling-mounting kit ③ Mounting hole (drilled on the ceiling) ④ Ceiling Figure 3.28 HCS-5300TH/80 digital infrared transceiver ceiling mounted Mounting steps: Step 1: Install the ceiling mounting kit at the top of the HCS-5300TH/80 Transceiver; Step 2: Drill a hole with 98 mm diameter into the ceiling (for mounting and heat elimination during operation);...
  • Page 79 3.5.3.2 Tripod mounted (Adjustable angle) ① HCS-5300TH/80 digital infrared transceiver ② M3 screw ③ Wall-mounted bracket (with flexible tube) ④ Tripod-mounted stator ⑤ HCS-5300TZJ2 (should be ordered separately) Figure 3.29 HCS-5300TH/80 digital infrared transceiver tripod mounted Mounting steps: Step 1: Fix the HCS-5300TH/80 digital infrared transceiver onto the wall-mounted bracket with M3 screws; Step 2: Fix the tripod-mounted stator onto the other end of the wall-mounted bracket with M3 screws;...
  • Page 80 3.5.3.3 Wall mounted (Adjustable angle) ① HCS-5300TH/80 digital infrared transceiver ② M3 screw ③ Wall-mounted bracket (with flexible tube) ④ PA3 self-tapping screws ⑤ Wall Figure 3.30 HCS-5300TH/80 digital infrared transceiver wall mounted Mounting steps: Step 1: Fix the HCS-5300TH/80 digital infrared transceiver onto the wall-mounted bracket with M3 screws; Step 2: Position the wall-mounted bracket on the wall according to the installation location of the HCS-5300TH/80 and mark the positions of the drilling holes.

  • Page 81: Installation Of Hcs-5300Twn/80

    3.5.4 Installation of HCS-5300TWN/80 3.5.4.1 Ceiling mounted ① HCS-5300TWN/80 digital infrared transceiver ② HCS-5300TWN/80 digital infrared transceiver mounting kit ③ M6×70 screws and nuts ④ Mounting holes (drilling on ceiling) Figure 3.31 HCS-5300TWN/80 digital infrared transceiver ceiling mounted Mounting steps: Step 1: Install the mounting kit at the top of the HCS-5300TWN/80 Transceiver;...
  • Page 82 3.5.4.2 Tripod mounted ① HCS-5300TWN/80 digital infrared transceiver ② HCS-5300TWN/80 digital infrared transceiver mounting kit ③ HCS-5300TZJ2 (should be ordered separately) Figure 3.32 HCS-5300TWN/80 digital infrared transceiver tripod mounted Mounting steps: Step 1: Fix the HCS-5300TWN/80 digital infrared transceiver onto the mounting kit (horizontal or longitudinal installation); Step 2: Fasten the fixing holes of the mounting kit through the screw on the tripod and fix it with a nut.
  • Page 83 3.5.4.3 Wall mounted 1 (Adjustable angle) ① HCS-5300TWN/80 digital infrared transceiver ② M3 screw ③ Wall-mounted bracket (with flexible tube) ④ PA3 self-tapping screws ⑤ Wall Figure 3.33 HCS-5300TWN/80 digital infrared transceiver wall mounted1 Mounting steps: Step 1: Fix the HCS-5300TWN/80 digital infrared transceiver onto the wall-mounted bracket with M3 screws; Step 2: Position the wall-mounted bracket on the wall according to the installation location of the HCS-5300TWN/80 and mark the positions of the drilling holes.
  • Page 84 3.5.4.4 Wall mounted 2 ① HCS-5300TWN/80 digital infrared transceiver ② KA3×12 screws ③ Wall Figure 3.34 HCS-5300TWN/80 digital infrared transceiver wall mounted2 Mounting steps: Step 1: Drill two holes (5 mm diameter, 30 mm depth, 204 mm spaced in vertical direction) on the wall according to installation location of the HCS-5300TWN/80;...

  • Page 85: Connecting To Main Unit

    3.6 Connecting to main unit Connect the transceiver to the main unit with designated 6-pin 100 Mbps high speed cable. Figure 3.31 Digital infrared transceiver connecting to digital infrared wireless conference main unit Note:  The correctness of the cable connection can be ascertained if the indicating light on the transceiver is lighting up.

  • Page 86: Technical Data

    3.7 Technical data Type HCS-5300TD/80 HCS-5300TDS/80 Voltage 33 V DC (supplied from HCS-5300) Max. 550 mA Current consumption Tripod, wall or ceiling mounted Suspension Mounting Wavelength 870 nm Modulation method DQPSK Carrier frequency 1 ~ 8 MHz Area radius from the point underneath the unit Approx.
  • Page 87 Type HCS-5300TH/80 HCS-5300TWN/80 33 V DC（supplied from HCS-5300M） 33 V DC（supplied from HCS-5300M） Voltage 24 V DC（supplied from HCS-ADP24V） 24 V DC (supplied from HCS-ADP24V2) Max. 550 mA Max. 650 mA (supplied from HCS-5300M） Current consumption Max. 650 mA (supplied from adapter) Tripod, wall or ceiling mounted Mounting Wavelength...

  • Page 88: Chapter 4 Digital Infrared Wireless Conference Unit

    Chapter 4 Digital infrared wireless conference unit 4.1 HCS-5300/80 Series 4.1.1 Overview HCS-5300/80 series digital infrared wireless conference units are the basic devices for the participators, divided into delegate unit and chairman unit with priority features. Different functions are available, depending on the conference unit type used.

  • Page 89: Functions And Indicating

    4.1.2 Functions and indicating HCS-5300CE/80 HCS-5300DE/80 HCS-5302D/80 HCS-5302C/80 Bottom side HCS-5301D/80 Left side ( functions for 5301D/80 only ) Right side Figure 4.1 HCS-5300/80 series digital infrared wireless conference unit...
  • Page 90 Figure 4.1: 1. Infrared transmitting/receiving glass – at the the priority button to activate it;  frontage of the conference unit for transmitting/ If “Ring” mode was set as “On” in the main unit receiving infrared signals. configuration, pressing this button will emit a ring tone.
  • Page 91  Start/Stop/Candidate5/Response++ (“START/STOP/5/++”): In opinion poll state of voting mode, voting indicating light will blink, press this button to vote for candidate 5; In audience response state of voting mode, voting indicating light will blink, press this button to give a response “100” of “100” (“++”); 10.

  • Page 92: Infrared Service Area

    In the vertical direction, the emission angle is 125°, directly faces a transceiver. Every HCS-5300/80 series and in the horizontal , the emission angle is 120°. digital infrared wireless conference unit is equipped with infrared glass at its frontage to guarantee Figure 4.2 Coverage area of new generation digital infrared wireless conference unit...

  • Page 93: Precautions In Using

     4.1.4 Precautions in using The distance between the conference unit and the nearest transceiver must be at least 2  Avoid direct sunshine when using, otherwise it meters or more. may cause signal blocking. Figure 4.3 Close curtain to avoid direct sunshine Figure 4.5 Distance between conference unit and transceiver ...

  • Page 94: Operation

    4 in the system. suitable for MS**E type stem microphone.  “Apply” (application software needed) Figure 4.6 HCS-5300/80 series conference unit with  If the Mic. request limit (set up by PC) has not microphone been reached, pressing the “Mic. On/Off” button can request to speak;...
  • Page 95 vote only once, and his/her voting indicating lights will be deactivated after his/her voting;  For “Last key-press valid” voting, the delegate can Strong Middle Weak change his/her vote. When the delegate voted, the Key press sign-in (application software needed) indicating light of his voted key will be activated and In sign-in mode, sign-in indicating light will blink.

  • Page 96: Technical Data

    4.1.6 Technical data Type HCS-5300CE/80 HCS-5300DE/80 HCS-5301D/80 HCS-5302D/80 HCS-5302C/80 √ √ √ √ √ Discussion Voting 5 keys 2×（1+7） Simultaneous interpretation 1+7 channels 1+7channels channels √ √ Priority key Voltage 10.95 V DC (HCS-5300BAT battery); 15 V DC (HCS-ADP15V power adapter) When Mic on: 320 mA Current consumption When Mic off: 65 mA...
  • Page 97 Type HCS-5300CE/80 HCS-5300DE/80 HCS-5301D/80 HCS-5302D/80 HCS-5302C/80 Dimensions Weight (excl. battery) 0.5 kg Weight (incl. battery) 0.8 kg Color Silver/ Charcoal gray...

  • Page 98: Hcs-5380 Series

    4.2 HCS-5380 Series 4.2.1 Overview HCS-5380 series digital infrared wireless conference units are the basic devices for the participators, divided into delegate unit and chairman unit with priority features. Different functions are available, depending on the conference unit type used. Functions include: listen, speak, OLED display,...

  • Page 99: Functions And Indicating

    4.2.2 Functions and indicating HCS-5380CVS HCS-5380DVS HCS-5380D HCS-5380C HCS-5380DDS HCS-5380DS Side Back Figure 4.9 HCS-5380 series digital infrared wireless conference unit...
  • Page 100 Figure 4.9: 1. Infrared transmitting/receiving glass – at the 8. Priority button (for chairman unit only)  frontage of the conference unit for transmitting/ If configured as “All mute”, all active microphones receiving infrared signals. will be muted temporarily when the priority button is pressed and they will resume when the priority Note: button is released;...

  • Page 101: Infrared Service Area

    4.2.3 Infrared service area 4.2.4 Precautions in using  Infrared light is directional invisible light. Infrared Avoid direct sunshine when using, otherwise it wireless conference unit gets best sensitivity when it may cause signal blocking. directly faces a transceiver. Every HCS-5380 series digital infrared wireless conference unit is equipped with infrared glass at its frontage to guarantee maximum receiving angle.

  • Page 102: Operation

    “Override” functions. The delegate unit can be set as VIP unit by  If the Mic. active limit (1/2/3/4) has not been software (TAIDEN Digital Conference System). reached, pressing the “Mic. On/Off” button will turn on the microphone;  Speaking indicating If the Mic.
  • Page 103  “Apply” (application software needed)  If the Mic. request limit (set up by PC) has not been reached, pressing the “Mic. On/Off” button can request to speak; If simultaneous interpretation function is operated and the  If the Mic. active limit (1/2/3/4) has been reached, earphone plugged simultaneous...
  • Page 104  If the priority mode is set as “All off” in the main unit configuration, all active conference units will be turned off automatically when the priority button on the chairman unit is pressed. Note:  When there is more than one chairman unit in a system and if one chairman is pressing the priority key, the priority keys of the remaining chairman units will be inoperable temporarily.

  • Page 105: Technical Data

    4.2.6 Technical data Type HCS-5380C series HCS-5380D series Voltage Built-in 3.7 V/5200 mAh recharge battery; 5 V, 2 A (TES-ADP5V power adapter) Wavelength 870 nm (AM: Brightness modulation) Modulation method DQPSK Transmission: Control channel: 3.8 MHz Audio channel 1: 4.3 MHz Audio channel 2: 4.8 MHz Carrier frequency Audio channel 3: 5.8 MHz...

  • Page 106: Hcs-5381 Series

    4.3 HCS-5381 Series 4.3.1 Overview HCS-5381 series digital infrared wireless conference units are the basic devices for the participators, divided into delegate unit and chairman unit with priority features. Types： HCS-5381RC Digital IR Wireless Chairman Unit (rectangular columnar metal microphone, discussion) HCS-5381RD Digital IR Wireless Delegate Unit (rectangular columnar metal microphone, discussion)

  • Page 107: Functions And Indicating

    4.3.2 Functions and indicating HCS-5381R series (front) side back HCS-5381C/D (front) Figure 4.15 HCS-5381 series digital infrared wireless conference unit Figure 4.15:  1. Infrared transmitting/receiving glass – at the Delegate unit: frontage of the conference unit for transmitting/ Turn on/off mic in “Override” mode; receiving infrared signals.
  • Page 108 be turned off automatically when the priority button is pressed;  If the chairman microphone is not active, pressing the priority button to activate it;  If “Ring” mode was set as “On” in the main unit configuration, pressing this button will emit a ring tone.

  • Page 109: Infrared Service Area

    4.3.3 Infrared service area 4.3.4 Precautions in using  Infrared light is directional invisible light. Infrared Avoid direct sunshine when using, otherwise it wireless conference unit gets best sensitivity when it may cause signal blocking. directly faces a transceiver. Every HCS-5381 series digital infrared wireless conference unit is equipped with infrared glass at its frontage to guarantee maximum receiving angle.

  • Page 110: Operation

    4.3.5 Operation The operation of the chairman unit and the delegate unit will be introduced in detail in this section. 4.3.5.1 The operation of delegate unit  If the Mic. active limit has been reached, all other microphones cannot be activated unless one of 1.
  • Page 111 4. Charging HCS-5381 conference unit can be charged with TES-ADP5V adapter, or be charged in HCS-5380CHG/06 charging unit. The charging indicator lights up for indication of the current power status and battery status when charging: Charging indicator Charging Flash Full After power on, the battery status will indicate via the battery indicator: Battery indicator...

  • Page 112: Technical Data

    4.3.6 Technical data Type HCS-5381RC HCS-5381RD Voltage Built-in 3.7 V/5200 mAh recharge battery; 5 V, 2 A (TES-ADP5V power adapter) Wavelength 870 nm (AM: Brightness modulation) Modulation method DQPSK Transmission: Control channel: 3.8 MHz Audio channel 1: 4.3 MHz Audio channel 2: 4.8 MHz Carrier frequency Audio channel 3: 5.8 MHz Audio channel 4: 6.3 MHz...
  • Page 113 Type HCS-5381C HCS-5381D Voltage Built-in 3.7 V/5200 mAh recharge battery; 5 V, 2 A (TES-ADP5V power adapter) Wavelength 870 nm (AM: Brightness modulation) Modulation method DQPSK Transmission: Control channel: 3.8 MHz Audio channel 1: 4.3 MHz Audio channel 2: 4.8 MHz Carrier frequency Audio channel 3: 5.8 MHz Audio channel 4: 6.3 MHz...

  • Page 114: Hcs-5390 Series

    HCS-5391DE HCS-5390 series sports a striking new design with Digital IR Wireless Delegate Unit (discussion, Braille, TAIDEN's user－centered philosophy at its core. The modern gray, excl. battery, stem microphone to be design is meant to embody bridging communication ordered separately) between participants inspired by the shape of a book.

  • Page 115: Functions And Indicating

    4.4.2 Functions and indicating HCS-5390CE HCS-5390DE HCS-5391DE HCS-5391CE HCS-5390RDAE HCS-5390RCAE HCS-5391RCAE HCS-5390RDAE...
  • Page 116 Left Side Right Side Bottom side Figure 4.21 HCS-5390 series digital infrared wireless conference unit Figure 4.21: 1. Infrared transmitting/receiving glass – at the Speaking frontage of the conference unit for transmitting/ Red For Mic. Apply Green Green receiving infrared signals. Voice Green (no speaking)
  • Page 117 c. In audience response state of voting mode, voting indicating light will blink, press this button to give a response “25” of “100” (“-”).  No/ Candidate 3/Response 0 (“NO/3/0”): a. In parliamentary state of voting mode, voting indicating light will blink, press this button to oppose;...

  • Page 118: Infrared Service Area

    4.4.3 Infrared service area Infrared light is directional invisible light. Infrared with infrared glass at its frontage to guarantee wireless conference unit gets best sensitivity when it maximum receiving angle. In the vertical direction, the directly faces a transceiver. Every HCS-5390 series emission angle is 125°, and in the horizontal , the digital infrared wireless conference unit is equipped emission angle is 120°.

  • Page 119: Precautions In Using

     4.4.4 Precautions in using The distance between the conference unit and the nearest transceiver must be at least 2  Avoid direct sunshine when using, otherwise it meters or more. may cause signal blocking. Figure 4.24 Close curtain to avoid direct sunshine Figure 4.26 Distance between conference unit and transceiver ...

  • Page 120: Operation

    4 in the system, the VIP/chairman of delegate units feature all or part of the functions. The microphones can be activated till the number delegate unit can be set as VIP unit by software (TAIDEN reaches 4, and then if another VIP/chairman Digital Conference System).
  • Page 121 to vote; the delegate unit is connected to the conference system  For “First key-press valid” voting, the delegate can and the IR signal is normal vote only once, and his/her voting indicating lights will Note: be deactivated after his/her voting; ...
  • Page 122 4.4.5.2 The operation of chairman unit The chairman unit features the functions of a delegate unit and in addition priority function:  If the priority mode is set as “All mute” in the main unit configuration, all active conference units will be muted when the priority button on the chairman unit is pressed and return active when the priority button on the chairman unit is released;...

  • Page 123: Technical Data

    4.4.6 Technical data Type HCS-5390CE HCS-5390DE HCS-5391CE HCS-5391DE √ √ √ √ Discussion Voting 5 keys 5 keys Simultaneous interpretation 1+7 channels 1+7 channels √ √ Priority key Voltage 10.95 V DC (HCS-5300BAT battery); 15 V DC (HCS-ADP15V power adapter) When Mic on: 300 mA Current consumption When Mic off: 75 mA...
  • Page 124 Type HCS-5390RCA HCS-5390RDA HCS-5391RCA HCS-5391RDA √ √ √ √ Discussion Voting 5 keys 5 keys Simultaneous interpretation 1+7 channels 1+7 channels √ √ Priority key Voltage 10.95 V DC (HCS-5300BAT battery); 15 V DC (HCS-ADP15V power adapter) Current consumption When Mic on: 300 mA; When Mic off: 65 mA Wavelength 870 nm (AM: Brightness modulation) Modulation method...

  • Page 125: Chapter 5 Web Control Software

    Chapter 5 Web control software Apply model: HCS-5300MA/80A, HCS-5300MB/80A, HCS-5300MC/80A; Running environment: browser for Firefox29.0, Google25.0, IE10 or higher. 5.1 Login and exit The user inputs the IP address of the CMU into the Web browser to login. The default UserName is “admin” and the default password is “123456”, the password can be changed after login.
  • Page 126 Input the UserName and password, then click the “Login” button and it will enter the conference management system interface automatically. Figure 5.3 Conference Management System There are two buttons in the right top of the interface:  Password Change: click this button and the below dialog box is shown: Figure 5.4 Change Password Input the Old Password, New Password and Password Confirm, and then click the “OK”...

  • Page 127: Conference Management

    5.2 Conference management 5.2.1 Assign unit ID to delegate It will list all ID of connective units in the system. User can assign them to delegates, open microphones, set up the camera predefine position, etc.. The interface is shown in the following figure: Figure 5.5 Assign Unit ID to Delegate ...

  • Page 128: Speaking And Request List

    5.2.2 Speaking and request list Speaking and Request List displays the information of the active and requested microphones, includes Mic. ID, delegate name, camera control and unit type. Figure 5.7 Speaking and Request List  Turn Off All Mic.: turn off all the microphones on the speaking list; ...

  • Page 129: Cmu Setting

    5.2.3 CMU setting CMU Setting includes Operation Mode, Active Microphones and Loudspeaker Volume. The CMU Setting interface as shown in the following figure: Figure 5.8 CMU Setting  Operation Mode: set up the speaking mode, include Open/ Override/ Voice/ Apply; ♦...

  • Page 130: Video Matrix

    5.2.4 Video matrix It includes Video Matrix and Video Switch. The matrix, TMX-0804, is a high definition video matrix which includes one 8x4 video matrix. 5.2.4.1 Video Matrix The setup of the Video Matrix interface is shown in the following figure: Figure 5.9 Video Matrix ...
  • Page 131 5.2.4.2 Video Switch The interface of the Video Switch is shown in the following figure: Figure 5.10 Video Switch Matrix switch: According to the setup of the video matrix, the video input type will be displayed automatically; Assign corresponding output channel by clicking on the cross point of input and output; Select “Video Track”...

  • Page 132: Predefined Position

    5.2.5 Predefined position If the conference system is equipped with cameras, the system can carry out automatic video tracking, i.e. display the image of the speaking participator to the display devices (large screen, TV, and so on). Predefine position is to set the predefined position of each microphone.

  • Page 133: Setup

    5.2.6 S.I. setup It includes channels, booths and language setting. The interface of S.I. setup is shown in the following figure: Figure 5.12 S.I. setup  Channels: supports 7 S.I. channels at most. If there are wired conference units connected, the maximal number of channels is 3;...
  • Page 134 Figure 5.13 Language Note:  The user-defined language only supports a sequence of numbers or letters (case sensitive) with a maximum of 8 characters, the abbreviation supports a maximum of 3 characters.

  • Page 135: Chapter 6 Accessories

    Chapter 6 Accessories 6.1 Digital IR conference room switcher 6.1.1 HCS-5300MX 6.1.1.1 Functions and indicating Front panel of HCS-5300MX Rear panel of HCS-5300MX Figure 6.1 HCS-5300MX Digital IR Conference Room Switcher Figure 6.1: 1. Power switch 8. Input channels（1-4）  For connecting to HCS-5300M Digital IR Wireless 2.
  • Page 136 6.1.1.2 Connection 1 Conference rooms combination 1 Several meeting rooms can be combined at leisure through the HCS-5300MX Digital IR Conference Room Switcher with CBL5300 cable. One HCS-5300MX can combine up to four meeting rooms. Figure 6.2 Room Combination 1 Note: ...
  • Page 137 6.1.2.2 Conference rooms combination 2 Several meeting rooms can be split/combined at leisure meeting rooms can be combined up at most to realize through the HCS-5300MX with CBL5300 cable to discussion, 1+7CHs simultaneous interpretation, central connect the transceivers and the HCS-8300MX with control, etc..
  • Page 138 6.1.1.3 Configuration and operation Switch on HCS-5300MX Digital IR Conference Room Switcher, it will start initialization: When the initialization is finished, the corresponding state of input channels and output groups will be displayed on the LCD: Press the button at the front panel and go to the next operation: ...
  • Page 139 6.1.1.4 Technical data Type HCS-5300MX Mains voltage AC 100 V - 120 V 60 Hz or AC 220 V - 240 V 50 Hz 15 W Power consumption 430 W Max. consumption 4 6P-DIN sockets Input interfaces 20 6P-DIN sockets in 4 groups, 5 sockets per group Output interfaces Dimensions Weight...

  • Page 140: Hcs-5300Mx/20

    6.1.2 HCS-5300MX/20 6.1.2.1 Functions and indicating Front panel of HCS-5300MX/20 Rear panel of HCS-5300MX/20 Figure 6.4 HCS-5300MX/20 Digital IR Conference Room Switcher Figure 6.4: 1. Power switch TSW-5300MX Room Switcher Tool 2. 16×2 segment LCD 11. Power supply 3. “MENU” button ...
  • Page 141 6.1.2.2 Connection 1. Conference rooms combination 1 Several meeting rooms can be combined at leisure through the HCS-5300MX/20 Digital IR Conference Room Switcher with CBL5300 cable. HCS-5300MX/20 can combine up to four meeting rooms. Figure 6.5 Room Combination 1 Note: ...
  • Page 142 2. Conference rooms combination 2 Several meeting rooms can be split/combined at leisure meeting rooms can be combined up at most to realize through the HCS-5300MX/20 with CBL5300 cable to discussion, 1+7CHs simultaneous interpretation, central connect the transceivers and the HCS-8300MX with control, etc..
  • Page 143 6.1.1.3 Configuration and operation the switcher will be displayed on the LCD. Switch on HCS-5300MX/20 Digital IR Conference Room Switcher, it will start initialization:  Channel switch operation:  Press the “INPUT 1…4” button to select the input When the initialization is finished, the corresponding state channel, the corresponding indicator lights up;...
  • Page 144 6.1.2.4 Technical data Type HCS-5300MX/20 Mains voltage AC 100V-240V 50Hz/60Hz 15 W Power consumption 500 W Max. consumption 4 6P-DIN sockets Input interfaces 20 6P-DIN sockets in 4 groups, 5 sockets per group Output interfaces Dimensions Weight 10.6 kg Color White...

  • Page 145: Lithium Battery

    14 × 67 × 37 mm Weight 93 g Color Blue Figure 6.6 HCS-5300/80 Series  HCS-5300BAT Lithium Rechargeable Battery Pack HCS-5300/80 and HCS-5390 series can be power supplied by specific Lithium battery or power adapter. Figure 6.5 HCS-5300BAT Lithium battery ...
  • Page 146 Figure 6.8 HCS-5300/80 Series Figure 6.8 HCS-5390 Series...

  • Page 147: Charging Device

    6.3 Charging device 6.3.1 HCS-5300CHG/08 charging unit LED Status Charging Status The charging unit can recharge up to 8 HCS-5300BAT Green Fully charged batteries at one time by using universal power supply with Charging automatic voltage matching. A charging indicator and a LED off Charging unit power off Green/Red...

  • Page 148: Hcs-5300Chg/06 Charging Unit

    6.3.2 HCS-5300CHG/06 charging unit 6.3.3 HCS-5300CHG/06A charging unit The charging unit can recharge up to 6 HCS-5380/5381 The charging unit can recharge up to 6 HCS-5380 series series conference units at one time by using 9 VDC, 6 A conference units at one time by using 9 VDC, 6 A power power adapter.

  • Page 149: Hcs-5390Chg Charging Unit

     6.3.4 HCS-5390CHG charging unit Charging procedure: Connect power core; The charging unit can recharge up to 2 HCS-5300BAT Switch on; batteries and 6 HCS-5390/HCS-5391 series digital Insert HCS-5300BAT batteries; Battery charging infrared conference units at one time by using universal indicator lights up to indicate battery status;...

  • Page 150: Dedicated Extension Cable For Digital Infrared Transceiver

    6.4 Dedicated extension cable for digital infrared transceiver CBL5300 dedicated cable is used to connect the digital infrared transceiver and the digital infrared wireless conference main unit. It features one male 6P-DIN connector at one end and one female 6P-DIN connector at the opposite end.

  • Page 151: Power Adapter

    HCS-ADP24V2 power adapter Connect the HCS-ADP15V to the power adapter Connect the HCS-ADP24V2 to the power adapter interface at the bottom of the HCS-5300/80 series new interface at the bottom of the HCS-5300TWN/80 digital generation digital infrared wireless conference unit.

  • Page 152: Hcs-5300Tzj2 Transceiver Stand

    6.6 HCS-5300TZJ2 transceiver stand Figure 6.17 HCS-5300TZJ2 HCS-5300TZJ2 transceiver stand is used to mount the HCS-5300TD/80, its height can be adjusted from 1.1 m to 2.7 m. For the installation method, refer to section  Technical data Used to install HCS-5300TD or HCS-5300TH/80 Maximum height: 2.7 meters Weight...

  • Page 153: Ms**E Type Stem Microphone

    6.7 MS**E type and MS5* type stem microphone Type MSxxEGF1 MS33EGFSB MSxxEGA1 MSxxEGB1 MSxxEGE1S MSxxEGG1B MSxxEGF2B MSxxEHA1B MS5G-xxB Picture Length 33/41/47 33/41/47 33/41/47 33/41/47 50/60/70 33/41 33/41/47 (cm) Champagne Champagne Color Black Black Black Black Black Silver/Black Champagne /Black / Black MIC-CAPM MIC-CAPM lockable...

  • Page 154: Earphones

    6.8 Earphones The earphones are connected to the conference units via an Ø 3.5 mm stereo jack. Suitable earphone types  EP-830 single earphone include:  EP-820AS single earphone  Technical data Used with the receiver/conference unit  Technical data Hi-Fi sound quality Used with the receiver/conference unit Ø...
  • Page 155  EP-960BH headphone  Technical data Used with the receiver/conference unit Hi-Fi sound quality 150 Ohm×2, Ø 3.5 mm stereo jack Frequency response 20 Hz to 20 kHz ≥108 dBA/1 mW Sensitivity One sided wire Weight 70 g...

  • Page 156: Chapter 7 Fault Diagnosis

    Not fully charged. battery. Use new batteries (complete set). Battery working time Out of battery service life (HCS-5300/80 Note: every new battery can be charged short. & HCS-5390 series). about 300 times. Please contact the local TAIDEN service Poor transceiver planning center.

  • Page 157: Digital Infrared Wireless Main Unit

    Change the fuse. powered on. The fuse has blown. Please contact the local TAIDEN service center. The charging indicating light of Plug-in the battery properly into the The battery is not properly plugged-in.

  • Page 158: Appendix

    Appendix Display language list Chinese English Abbreviations Chinese English Abbreviations 原声 ┄ 吉尔吉斯语 Floor Kirghiz 阿尔巴尼亚 老挝语 Albanian 阿拉伯语 蒙古语 Arabic Mongolian 保加利亚语 尼泊尔语 Bulgarian Nepali 加泰罗利亚 塔吉克语 Catalan Tajik 汉语 泰语 Chinese Thai 捷克语 藏语 Czech Tibetan 丹麦语 土库曼斯坦 Danish Turkmen 荷兰语...
  • Page 159 Chinese English Chinese English Abbreviations Abbreviations 梵文 祖鲁语 Sanskrit Zulu 信德语 壮族语 Sindhi Zhuang 僧加罗语 傣族语 Sinhala 梭托语 维吾尔语 Southern Sotho Uighur 斯瓦西里语 文莱语 Swahili Brunei 泰米尔语 新加坡 Tamil Singapore 泰卢固语 印度语 Telugu Hindi 茨瓦纳语 马其他语 Tswana Maltese 乌尔都语 乌兹别克语 Urdu Uzbek 威尔士语...

  • Page 160: Dedicated 6 Pin Extension Cable

    Dedicated 6 PIN Extension Cable...

  • Page 162: Microphone Stem Precautions

    Microphone Stem Precautions...
  • Page 163 TAIDEN INDUSTRIAL CO., LTD. 6/F, Block B, Future Plaza, 4060 Qiaoxiang Rd, Nanshan District, Shenzhen China Website: http://www.taiden.com Last Revision: 11/2024 Copyright © 2008-2024 TAIDEN Industrial Co., Ltd. All Rights Reserved.

This manual is also suitable for:

Hcs-5300ma/80aHcs-5300mb/80aHcs-5300mc/80aHcs-5300td/80Hcs-5300tds/80Hcs-5300th/80 ... Show all

Table of Contents
