Page 3: Connection And Operation
2.3 Connection and operation 1. Connection nameplates to main unit nameplates one by one. Once all nameplates numbered, restart the CMU to update the number There are two ways for electronic nameplates to information. access main unit: First, the electronic nameplates are directly connected Note: to the conference units (eg. - Page 4 Picture format: *.bmp, monochrome bitmap; Nameplate resolution: 1904*464; Front screen file name: 1.BMP; Back screen file name: 2.BMP; Double screens file name: 3.BMP. 4. Display Display content can be set through nameplate system software, contents may be permanently displayed after power down.
