Page 2: Table Of Contents
CONTENTS 01/ Safety Information ....................2 02/ Technical Specifications ..................3 03/ Application Software Installation ................ 4 04/ Using the DMX Interface ..................7 05/ Fixture Cleaning ...................... 9 - 1 -... -
Page 3: 01/ Safety Information
01/ Safety Information Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty. -
Page 4: 02/ Technical Specifications
DO NOT operate this product if you see damage on the housing, shields, or cables. Have the damaged parts replaced by an authorized technician at once. 02/ Technical Specifications Uploader Included Items USB Cable User Manual (this document) Dimensions 98x53x40mm 3.9"x2.1"x1.6"... -
Page 5: 03/ Application Software Installation
03/ Application Software Installation 1. Download the ACME Upgrade application software from the ACME website. 2. Double-click on the application software to start installation. Click “Next>”. - 4 -... - Page 6 3. Accept the default installation directory, or click “Browse” to specify another one. Click “Next>”. 4. Click “Next>” to start the installation process. - 5 -...
- Page 7 5. Click “Close” to exit the installation program after the installation process is complete. - 6 -...
-
Page 8: 04/ Using The Dmx Interface
04/ Using the DMX Interface 1. Use the USB cable to connect the Uploader device to a personal computer that has the Uploader application software installed on it. 2. Connect the Uploader device to lighting fixtures via a DMX network. - Page 9 To stop emitting DMX signals, click “Stand Alone” (the red LED signal indicator on the Uploader device will be turn off). 5. Click “Fixture Firmware Upgrade”. 6. Click “Open” and select the firmware file that you have downloaded for the fixture. Click “Upgrade”...
-
Page 10: 05/ Fixture Cleaning
05/ Fixture Cleaning It is absolutely essential that the fixture is kept clean. The fixture must be cleaned regularly to avoid dust, dirt and smoke-fluid residues building up on or within the fixture. The cleaning frequency depends on the application environment. Clean the fixture immediately if the dust enters it to avoid damage due to excessive dust.
