  • Page 2: Table Of Contents

    REV K 09/26/2024 CONTENTS 01/ Safety Information ....................2 02/ Technical Specifications ..................7 03/ Overview ........................9 04/ Connecting Power and Data ................10 4.1 Connecting Power ..................10 4.2 Connecting Data.................... 11 05/ Fixture Installation ....................12 06/ Effect Wheels ......................15 07/ Operation .......................

  • Page 3: 01/ Safety Information

    REV K 09/26/2024 01/ Safety Information Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty.
  • Page 4 REV K 09/26/2024 Avoid any flammable liquids, water or metal from entering the unit. Once it happens, cut  off the mains power immediately. DO NOT operate in a dirty or dusty environment. DO clean the fixture regularly.  DO NOT touch any wire during operation as there might be a hazard of electric shock. ...
  • Page 5 REV K 09/26/2024 01/ Consignes de sécurité Veuillez lire attentivement les instructions qui contiennent des informations importantes sur l'installation, l'utilisation et l'entretien. ATTENTION Veuillez conserver ce guide de l'utilisateur pour une consultation future. Si vous vendez l'appareil à un autre utilisateur, assurez-vous qu'il reçoive également ce manuel d'instructions.
  • Page 6 REV K 09/26/2024 Assurez-vous que le cordon d'alimentation n'est pas pincé ou endommagé; remplacez-le  immédiatement s'il est endommagé. La température de surface de l'unité peut atteindre 75℃. NE PAS toucher les capots à  mains nues pendant son fonctionnement. Évitez que des liquides inflammables, de l'eau ou du métal ne pénètrent dans l'appareil.
  • Page 7 REV K 09/26/2024 Les sources externes de rayons lumineux provenant de la lumière directe du soleil ou de  toute autre source de lumière forte, qui pénètrent la lentille avant des appareils d'éclairage, peuvent causer de graves dommages internes. N'exposez PAS la lentille frontale du projecteur à...

  • Page 8: 02/ Technical Specifications

    REV K 09/26/2024 02/ Technical Specifications AC Power 100-240Vac; 50/60Hz Max. Power 1200W Consumption Light Source SCL1000Y-80-R72 Color Temperature 6500K Zoom Range 6°-50° Color Wheel 5 colors + frost + CRI Static Gobo Wheel 9 gobos + open Gobo Wheels Rotating Gobo Wheel 7 replaceable gobos + open 540°...
  • Page 9 REV K 09/26/2024 Motorized zoom Motorized focus Framing: rotatable framing module, +/-60°, 4 x individually controllable full framing blades with variable angle and position Power Cable with true1 power connector Included Items Two omega brackets with 1/4-turn fasteners User Manual (this document) Dimensions 412x330x719mm 16.2"x13"x28.3"...

  • Page 10: 03/ Overview

    REV K 09/26/2024 03/ Overview 1. Display To show the various menus and the selected function MENU To enter into move backward or leave the menu  UP To go backward to move up in the menu 2. Buttons  DOWN To go forward to move down in the menu ENTER To perform the desired functions...

  • Page 11: 04/ Connecting Power And Data

    REV K 09/26/2024 04/ Connecting Power and Data 4.1 Connecting Power To apply power, first check that the head pan and tilt locks are released. This fixture can operate on any 100-240Vac; 50/60Hz AC mains power supply. The maximum power consumption is 1200W. The fixture must be grounded/earthed and able to be isolated from AC power.

  • Page 12: Connecting Data

    REV K 09/26/2024 4.2 Connecting Data The fixture is equipped with 3-pin (or 5-pin) XLR sockets for DMX input and output. Use a high-quality DMX cable designed for RS-485 and 3-pin (or 5-pin) XLR-plugs and connectors in order to connect the controller with the fixture or one fixture with another. For outdoor installations, use only IP-rated XLR connectors suitable for outdoor use.

  • Page 13: 05/ Fixture Installation

    REV K 09/26/2024 05/ Fixture Installation The fixture is IP66-rated and designed for both indoor and outdoor events. This means that it is protected from:  Dust, to the degree that dust cannot enter the device in sufficient quantities as to interfere with its operation.
  • Page 14 REV K 09/26/2024 - 13 -...
  • Page 15 REV K 09/26/2024 Steps for installing omega brackets to the fixture: - 14 -...

  • Page 16: 06/ Effect Wheels

    REV K 09/26/2024 06/ Effect Wheels DANGER! Replace the rotating gobos with the device switched off only. Unplug from mains before replacing the rotating gobos! Static Gobo Wheel Rotating Gobo Wheel Slot Name Part Number Slot Name Part Number Open Empty Open Empty...
  • Page 17 REV K 09/26/2024 Follow these precautions when using and handling rotating gobos:  Original gobos have a special coating designed specifically to resist to high temperatures. Must use high temperature Borofloat or better glass. Replacement gobos must match the dimensions, construction, materials and quality as the gobos supplied as standard. Using gobos that do not meet this requirement can cause damage that is not covered by the product warranty.
  • Page 18 REV K 09/26/2024  Note how the gobo holder tongue engages in a recess in the gobo drive wheel when pulling the gobo holder out of the gobo wheel. You will need to reinstall the gobo holder with the tongue in the same position in the drive wheel. ...
  • Page 19 REV K 09/26/2024  Holding the new gobo by its edges, taking care to not leave fingerprints on the gobo, insert it into the gobo holder with the alignment marks on gobo and gobo holder oriented correctly and with the black side (or flat side of the textured glass gobos) facing downwards.

  • Page 20: 07/ Operation

    REV K 09/26/2024 07/ Operation 7.1 Control Menu  To access the control menus, press the [MENU] button.  Navigate the menu structure, using the [ENTER], [ UP] and [ DOWN] buttons.  To select a menu option or to confirm a selection, press the [ENTER] button. ...
  • Page 21 REV K 09/26/2024 MAIN MENU SUBMENU CHOICES/VALUES Square Law Inv SQ Law Dimmer Curve Linear S Curve 900Hz 1000Hz 1100Hz 1200Hz 1300Hz 1400Hz 1500Hz Led Refresh Rate 2500Hz 4000Hz 5000Hz 6000Hz 10KHz 15KHz 20KHz 25KHz Standard Cooling Mode Quiet Theatre Bright Calibration 50-100 (Default=100)
  • Page 22 REV K 09/26/2024 MAIN MENU SUBMENU CHOICES/VALUES Single Auto Test Cycle Clear No/Yes 0-255 Tilt 0-255 Cyan 0-255 Magenta 0-255 Yellow 0-255 0-255 Color 0-255 Gobo 0-255 R-Gobo 0-255 Gobo 2 0-255 Animation 0-255 Iris 0-255 Prism 1 0-255 R-Prism 1 0-255 Fixture Test Prism 2...
  • Page 23 REV K 09/26/2024 MAIN MENU SUBMENU CHOICES/VALUES Fixture Use Hour Total LED Hour LED Use Hour LED On Hour LED Hours Reset Password=050 Current Humidity Base Head Current Max temp Temperature Fixture Information LED’s B_FAN 1~3 Fan State A_FAN 1 H_FAN 1~12 Firmware Version RDM UID...

  • Page 24: Channel Mode

    REV K 09/26/2024 DMX Settings Enter the control menu and select DMX Settings, press ENTER. Use the UP/DOWN button to select DMX Address, DMX Channel Mode, No DMX Status or View DMX Value. DMX Address Select DMX Address, press ENTER. Use UP/DOWN button to select an address, confirm your selection with ENTER.
  • Page 25 REV K 09/26/2024 View DMX Value Select View DMX Value, press ENTER. Use UP/DOWN button to select the desired DMX channel, for which the value is to be displayed. To exit the menu, press MENU, or wait 30 seconds. Fixture Settings Enter the control menu and select Fixture Settings, press ENTER.
  • Page 26 REV K 09/26/2024 Dimmer Speed Select Dimmer Speed, press ENTER. Use UP/DOWN button to select Fast or Smooth, confirm your selection with ENTER. To exit the menu, press MENU, or wait 30 seconds. Dimmer Curve Select Dimmer Curve, press ENTER. Use UP/DOWN button to select Square Law, Inv SQ Law, Linear or S Curve, confirm your selection with ENTER.
  • Page 27 REV K 09/26/2024 Bright Calibration Select Bright Calibration, press ENTER. Use UP/DOWN button to select a value between 50 and 100, confirm your selection with ENTER. To exit the menu, press MENU, or wait 30 seconds. Blade Mode Select Blade Mode, press ENTER. Use UP/DOWN button to select Mode 1 or Mode 2, confirm your selection with ENTER.
  • Page 28 REV K 09/26/2024 Display Settings Enter the control menu and select Display Settings, press ENTER. Use the UP/DOWN button to select Display Invert, Backlight Intensity, Temperature Unit or Language. Display Invert Select Display Invert, press ENTER. Use UP/DOWN button to select No (display normal) or Yes (display inverted), confirm your selection with ENTER.
  • Page 29 REV K 09/26/2024 Fixture Test Enter the control menu and select Fixture Test, press ENTER. Use the UP/DOWN button to select Auto Test or Manual Test. Auto Test Select Auto Test, press ENTER. Use UP/DOWN button to select Single (the device immediately performs a single automatic self-test) or Cycle (the device immediately performs a cyclic automatic self-test), confirm your selection with ENTER.
  • Page 30 REV K 09/26/2024 LED Use Hour Select LED Use Hour, press ENTER. Use UP/DOWN button to select Total LED Hour (total time) or LED On Hour (current switch-on time), confirm your selection with ENTER. The total time or current switch-on time is displayed. Use UP/DOWN button to select LED Hours Reset, confirm your selection with ENTER.
  • Page 31 REV K 09/26/2024 Error Logs Select Error Logs, press ENTER. Use UP/DOWN button to select Fixture Errors, confirm your selection with ENTER. The error list is displayed. Use UP/DOWN button to select Reset Error Log, confirm your selection with ENTER. If you wish to reset the relevant error logs, select Yes.
  • Page 32 REV K 09/26/2024 All Reset Select All Reset, press ENTER. Use UP/DOWN button to select No or Yes (the device will run built-in program to reset all to their home positions), confirm your selection with ENTER. To exit the menu, press MENU, or wait 30 seconds. Special Function Enter the control menu and select Special Function, press ENTER.
  • Page 33 REV K 09/26/2024 RDM functions: Certain menus of the device and functions can be called up via the RDM protocol. The parameter IDs are implemented as follows for different commands: Command Command Command Parameter ID ‘Discovery’ ‘Set’ ‘Get’ DISC_UNIQUE_BRANCH √ DISC_MUTE √...

  • Page 34: Home Position Adjustment

    REV K 09/26/2024 7.2 Home Position Adjustment  To access the control menus, press the [MENU] button.  To access the offset menus, long-press the [ENTER] button.  Navigate the offset menus, using the [ENTER], [ UP] and [ DOWN] buttons. ...
  • Page 35 REV K 09/26/2024 Blade Down 1 -128~127 Blade Down 2 -128~127 Blade Up 1 -128~127 Blade Up 2 -128~127 Blade Left 1 -128~127 Blade Left 2 -128~127 Blade Right 1 -128~127 Blade Right 2 -128~127 Frequency(Hz) Select Frequency(Hz), press ENTER. Use UP/DOWN button to select a value, confirm your selection with ENTER.
  • Page 36 REV K 09/26/2024 Dimming Start Select Dimming Start, press ENTER. Use UP/DOWN button to select a value between 0 and 999, confirm your selection with ENTER. To exit the offset menu, press MENU, or wait 30 seconds. Dim 1 Offset Select Dim 1 Offset, press ENTER.
  • Page 37 REV K 09/26/2024 Cyan Select Cyan, press ENTER. Use UP/DOWN button to select a value between -128 and 127, confirm your selection with ENTER. To exit the offset menu, press MENU, or wait 30 seconds. Magenta Select Magenta, press ENTER. Use UP/DOWN button to select a value between -128 and 127, confirm your selection with ENTER.
  • Page 38 REV K 09/26/2024 R-Gobo Select R-Gobo, press ENTER. Use UP/DOWN button to select a value between -128 and 127, confirm your selection with ENTER. To exit the offset menu, press MENU, or wait 30 seconds. Gobo 2 Select Gobo 2, press ENTER. Use UP/DOWN button to select a value between -128 and 127, confirm your selection with ENTER.
  • Page 39 REV K 09/26/2024 Prism 2 Select Prism 2, press ENTER. Use UP/DOWN button to select a value between -128 and 127, confirm your selection with ENTER. To exit the offset menu, press MENU, or wait 30 seconds. R-Prism 2 Select R-Prism 2, press ENTER. Use UP/DOWN button to select a value between -128 and 127, confirm your selection with ENTER.
  • Page 40 REV K 09/26/2024 Blade Select Blade, press ENTER. Use UP/DOWN button to select a value between -128 and 127, confirm your selection with ENTER. To exit the offset menu, press MENU, or wait 30 seconds. Blade Down 1 Select Blade Down 1, press ENTER. Use UP/DOWN button to select a value between -128 and 127, confirm your selection with ENTER.
  • Page 41 REV K 09/26/2024 Blade Left 2 Select Blade Left 2, press ENTER. Use UP/DOWN button to select a value between -128 and 127, confirm your selection with ENTER. To exit the offset menu, press MENU, or wait 30 seconds. Blade Right 1 Select Blade Right 1, press ENTER.

  • Page 42: 08/ Configuring The Device For Dmx Control

    REV K 09/26/2024 08/ Configuring the Device for DMX Control 8.1 Address Setting All fixtures should be given a DMX starting address when operating with a DMX controller, in order to ensure that the correct fixture responds to the correct control signal. Incorrect settings will result in unpredictable responses from the lighting controller.

  • Page 43: Dmx Protocol

    REV K 09/26/2024 8.2 DMX Protocol CHANNEL VALUE FUNCTION 39ch 30ch 31ch 22ch 40ch 000-255 0°540° 000-255 PAN FINE TILT 000-255 0°260° 000-255 TILT FINE PAN/TILT SPEED 000-255 Fast to Slow CYAN 000-255 0%100% MAGENTA 000-255 0%100% YELLOW 000-255 0%100% 000-255 0%100% COLOR...
  • Page 44 REV K 09/26/2024 024-031 Gobo 3 032-039 Gobo 4 040-047 Gobo 5 048-055 Gobo 6 056-063 Gobo 7 064-072 Gobo 1 Shaking, Slow to Fast 073-081 Gobo 2 Shaking, Slow to Fast 082-090 Gobo 3 Shaking, Slow to Fast 091-099 Gobo 4 Shaking, Slow to Fast 100-108 Gobo 5 Shaking, Slow to Fast...
  • Page 45 REV K 09/26/2024 000-007 Close 008-255 Open R-PRISM 1 000-127 Index 0°360° 128-189 Counter-Clockwise Rotation, Fast to Slow 190-193 Stop 194-255 Clockwise Rotation, Slow to Fast PRISM 2 (4-facet linear prism) 000-007 Close 008-255 Open R-PRISM 2 Index 0°360° 000-127 128-189 Clockwise Rotation, Fast to Slow 190-193...
  • Page 46 REV K 09/26/2024 0%100% BLADE UP 2 000-255 0%100% BLADE LF 1 000-255 0%100% BLADE LF 2 000-255 0%100% BLADE RG 1 000-255 0%100% BLADE RG 2 000-255 0%100% FUNCTION (To activate following functions, stop in DMX value for at least 3 seconds.) 000-009 Null 010-019...

  • Page 47: 09/ Error Information

    REV K 09/26/2024 234-235 Color Short Cut: Enable 236-237 Color Short Cut: Disable 238-239 Null 240-245 Null 246-251 Null 252-255 Null 09/ Error Information Error codes are shown continuously in the display when the fixture fails and they will not disappear until the fixture is repaired.
  • Page 48 REV K 09/26/2024 Head Humi. Error Check whether the humidity sensor is faulty. Check whether the lead connecting the humidity sensor is installed in place or disconnected. Memory. Error When the memory IC keeps reporting errors, please replace the motherboard. Base Humi.
  • Page 49 REV K 09/26/2024 Tilt Reset Error Check whether the position of the tilt where the magnet is installed falls off or is damaged. Check whether there are obstacles in the tilt operating range. Check whether the Hall element on the tilt is damaged. Check whether the lead connecting the Hall element on the tilt and the PCB board is in poor contact or disconnected.
  • Page 50 REV K 09/26/2024 Magenta Reset Error Check whether the position of the magenta color wheel where the magnet is installed falls off or is damaged. Check whether there are obstacles in the magenta color wheel operating range. Check whether the Hall element on the magenta color wheel is damaged.
  • Page 51 REV K 09/26/2024 Cto Reset Error Check whether the position of the cto where the magnet is installed falls off or is damaged. Check whether there are obstacles in the cto operating range. Check whether the Hall element on the cto is damaged. Check whether the lead connecting the Hall element on the cto and the PCB board is in poor contact or disconnected.
  • Page 52 REV K 09/26/2024 Gobo1/2 Reset Error Check whether the position of the gobo wheel 1/2 where the magnet is installed falls off or is damaged. Check whether there are obstacles in the gobo wheel 1/2 operating range. Check whether the Hall element on the gobo wheel 1/2 is damaged. Check whether the lead connecting the Hall element on the gobo wheel 1/2 and the PCB board is in poor contact or disconnected.
  • Page 53 REV K 09/26/2024 Animation Reset Error Check whether the position of the animation wheel where the magnet is installed falls off or is damaged. Check whether there are obstacles in the animation wheel operating range. Check whether the Hall element on the animation wheel is damaged. Check whether the lead connecting the Hall element on the animation wheel and the PCB board is in poor contact or disconnected.
  • Page 54 REV K 09/26/2024 R-Prism1/2 Reset Error Check whether the position of the prism 1/2 where the magnet is installed falls off or is damaged. Check whether there are obstacles in the prism 1/2 operating range. Check whether the Hall element on the prism 1/2 is damaged. Check whether the lead connecting the Hall element on the prism 1/2 and the PCB board is in poor contact or disconnected.
  • Page 55 REV K 09/26/2024 Focus Reset Error Check whether the position of the focus where the magnet is installed falls off or is damaged. Check whether there are obstacles in the focus operating range. Check whether the Hall element on the focus is damaged. Check whether the lead connecting the Hall element on the focus and the PCB board is in poor contact or disconnected.
  • Page 56 REV K 09/26/2024 Arm Fan 1 Start Err Check whether the fan is not running. Check whether the fan leads are installed in place or disconnected. Check whether the fan is damaged. Check whether there are obstacles in the fan operating range. Head Fan 1/2/3/4/5/6/7/8/9/10/11/12 Start Err Check whether the fan is not running.
  • Page 57 REV K 09/26/2024 Position of cooling fans: Cooling Fans Part Number Position Base Fan 1 3014001293 DC 24V 4.8W Base - A Base Fan 2 Base Fan 3 3014001259 DC 24V 2.4W Base - B Arm Fan 1 3014001257 DC 24V 3.6W Head - E Head Fan 1...

  • Page 58: 10/ Troubleshooting

    REV K 09/26/2024 10/ Troubleshooting Problem Potential cause(s) Remedies Confirm that the power is switched No power to the fixture. Fixture does not respond on and cables are plugged in. or appears to be off. No output from PSU. Replace the PSU. Fixture suddenly turned Check the power supply, switches Power was turned off.

  • Page 59: 11/ Fixture Cleaning

    REV K 09/26/2024 11/ Fixture Cleaning Regular cleaning is very important for fixture life and performance. Buildup of dust, dirt, smoke particles, fog fluid residues, etc. degrades the fixture’s light output and cooling ability. Cleaning schedules for lighting fixtures vary greatly depending on the operating environment. It is therefore impossible to specify precise cleaning intervals for the fixture.

  • Page 60: 12/ Approvals And Certifications

    REV K 09/26/2024 12/ Approvals and Certifications This product has been tested and found to comply with the following standards: - 2014/30/EU - Electromagnetic Compatibility (EMC) - 2014/35/EU - Low Voltage Directive (LVD) - cETLus Approved (Control #5000057) - UK SI 2016 No. 1091: Electromagnetic Compatibility Regulations 2016 - UK SI 2016 No.
