OPERATING THE DEVICE

The device enables connecting switch to the S1 and S2 terminals. These can be monostable or bistable switches.
Switch buttons are responsible for managing the blind movement.
Description:
– Switch connected to the S1 terminal
– Switch connected to the S2 terminal
General tips:
• You can initiate, stop, or change the direction of movement using a switch or switches
• If you set flowerpot protection option the down movement action is performed only to a defined level.
• If you control only a venetian blind position (not slats rotation) the slats return to their previous position (in aperture level 0 - 95%).
Monostable switches – click to move
Example of the switch design:
Table A2 - Roll-Control2 - Monostable switches - click to move
Parameter: 20. Switch type
Description: This parameter determines which switch types and mode S1 and S2 inputs
operate with.
Set value: 0 - Monostable switches – click to move
Parameter: 151. Roller blind, Awning, Pergola or Curtain
Description:
1×click
Next click
1×click
2×click
Hold
Hold
Available values: 0
Parameter: 151. Venetian blind
Description:
1×click
Next click
1×click
2×click
Hold
Hold
Available values: 1 or 2
Favorite position – available
8
switch - Initiate up movement to the limit position
- stop
switch - Initiate down movement to the limit position
or switch - Favorite position
- Up movement until release
- Down movement until release
switch - Initiate up movement to the limit position
- move to the right position
switch - Initiate down movement to the limit position
or switch - Favorite position
- Turning slats up until release
- Turning slats down until release
