SPECIFICATIONS

Table A1 - Roll-Control2 - Specifications
Power supply
Rated load current
Compatible load types
Required limit switches
Recommended external
overcurrent protection
For installation in boxes
Recommended wires
Operating temperature
Ambient humidity
Radio protocol
Radio frequency band
Max. transmitting power
Range
Dimensions
(height x width x depth)
Compliance with EU directives
Note
Radio frequency of an individual device needs to be the same as your Z-Wave controller. Check information on the box or consult your dealer
if you aren't sure.
4
100-240 V~ 50/60 Hz
2 A for motors with compensated power factor (inductive loads)
single-phase AC motors
M
~
Electronic or mechanic
10 A type B circuit breaker (EU)
13 A type B circuit breaker (Sweden)
Ø
= 60 mm, depth ≥ 60 mm
Cross-section area between 0.75-1.5 mm
0 – 35°C
10 – 95% RH without condensation
Z-Wave (800 series chip)
EU: 868.4 MHz, 869.85 MHz
AH: 919.8 MHz, 921.4 MHz
+6dBm
up to 100 m outdoors up to 30 m indoors
(depending on terrain and building structure)
46 × 36 × 19.9 mm
RoHS 2011/65/EU
RED 2014/53/EU
stripped 8 - 9 mm of insulation
